MAIN COMPONENTS
1 Top cowling
2 Cowling lock lever
3 Oil drain bolt
4 Anti-cavitation plate
5 Trim tab (Anode)
6 Propeller
7 Cooling water inlet
8 Clamp bracket
9 Tilt support lever
0 Flushing device
q Power trim and tilt switch
w Remote control box
e Digital tachometer
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
*
*
