Yamaha F75C - Digital Tachometer

2-8
EMU00136
Tachometer
This meter shows the engine speed.
E
q
t
w
r
001081
e
y
u
001085
001058
EMU01617
DIGITAL TACHOMETER
This gauge contains the tachometer, trim
meter, hour meter, low oil pressure warn-
ing indicator, and the overheat warning
indicator.
1 Tachometer
2 Trim meter
3 Hour meter
4 Low oil pressure warning indicator
5 Overheat warning indicator
6 Set button
7 Mode button
NOTE:
All segments of the display will light
momentarily after the main switch is
turned on and will return to normal there-
after.
