4-26
6) When the oil begins to flow out of the
oil level plug hole, insert and tighten
the oil level plug.
7) Insert and tighten the oil drain plug.
Gear oil grade/capacity:
Refer to “SPECIFICATIONS,” page 4-1.
EMU14622
INSPECTING AND REPLACING
ANODE(S)
Yamaha outboard motors are protected
from corrosion by sacrificial anodes.
Inspect the external anodes periodically.
Remove scales from the surfaces of the
anodes. Consult a Yamaha dealer for
replacement of external anodes.
cC
Do not paint anodes, as this would ren-
der them ineffective.
NOTE:
Inspect ground leads attached to external
anodes on equipped models. Consult a
Yamaha dealer for inspection and
replacement of internal anodes attached
to the power unit.
F1027
