Yamaha F90 - Low Battery Voltage-Alert Indicator; 6 Y8 Multifunction Meters

Instruments and indicators
41
EMU26733
Low battery voltage-alert indicator
If battery voltage drops, the display will auto-
matically turn on and blink.
Get back to the port soon if an alert device
has activated. For charging the battery, con-
sult your Yamaha dealer.
EMU46654
6Y8 Multifunction meters
There are two types of 6Y8 Multifunction me-
ters.
z 6Y8 Multifunction tachometer
z 6Y8 Multifunction speed & fuel meter
6Y8 Multifunction tachometer
6Y8 Multifunction speed & fuel meter
1. Fuel level-alert segment
1. Low battery indicator
TRIP TIME BATT
km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
ZMU07005
1
TRIP TIME BATT
km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
ZMU07006
1
1. Set button
2. Mode button
1. Tachometer
2. Trim meter
3. Multifunction display
1. Set button
2. Mode button
SET MODE
21
ZMU08407
1 2
3
ZMU08408
SET MODE
21
ZMU08409
