Yamaha F90 - Shallow Water; Cruising in Shallow Water

Operation
70
EMU28063
Shallow water
EMU40702
Cruising in shallow water
The outboard motor can be tilted up partially
to allow operation in shallow water.
NOTICE
ECM02361
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32914
Procedure for power trim and tilt models
1. Place the remote control lever / gear shift
lever in neutral.
1. Power trim and tilt switch
1. Power trim and tilt switch
1
DN
ZMU08694
1. Cooling water inlet
1
ZMU08144
N
ZMU01771
N
ZMU04588
