PERIODIC MAINTENANCE AND MINOR REPAIR
6-19
6
EAU04051*
Cleaning the air filter element
The air filter element should be cleaned
at the intervals specified in the periodic
maintenance and lubrication chart.
Clean the air filter element more fre-
quently if you are riding in unusually
wet or dusty areas.
1. Remove the seat. (See page 3-11
for seat removal and installation
procedures.)
2. Remove the fuel tank bolts.
3. Lift the fuel tank to position it away
from the air filter case. (Do not dis-
connect the fuel hoses!)
EW000071
WARNING
_
●
Make sure that the fuel tank is
well supported.
●
Do not tilt or pull the fuel tank
too much, otherwise the fuel
hoses may come loose, which
could cause fuel leakage.
_
4. Remove panels A and C. (See
page 6-8 for panel removal and in-
stallation procedures.)
5. Pull the rubber cover off its hold-
ers.
1. Bolt (× 3) 1. Rubber cover
2. Rubber cover holder (× 2)
U5LV12.book Page 19 Thursday, June 27, 2002 5:49 PM
