Right view
10 912 11
23 546
871
1. Luggage strap holder (page 4-22)
2. Fuse box (page 7-31)
3. Battery (page 7-30)
4. Rear brake fluid reservoir (page 7-22)
5. Coolant reservoir (page 7-12)
6. Engine oil filler cap (page 7-9)
7. Front fork rebound damping force adjusting screw (page 4-19)
8. Front fork spring preload adjusting bolt (page 4-19)
9. Front fork compression damping force adjusting screw (page 4-19)
10.Engine oil level check window (page 7-9)
11.Brake pedal (page 4-13)
12.Rear brake light switch (page 7-21)
