Yamaha FZ8 - Replacing the Tail;Brake Light Bulb; Replacing a Turn Signal Light Bulb

PERIODIC MAINTENANCE AND ADJUSTMENT
7-35
7
13. Have a Yamaha dealer adjust the
headlight beam if necessary.
EAU24115
Replacing the tail/brake light
bulb
1. Remove the passenger seat. (See
page 4-17.)
2. Remove the tail/brake light bulb
socket (together with the bulb) by
turning it counterclockwise.
3. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
4. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
5. Install the socket (together with the
bulb) by turning it clockwise.
6. Install the passenger seat.
EAU24204
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screw.
2. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
1. Tail/brake light bulb socket
1
1. Turn signal light lens
2. Screw
1
2
