Yamaha HS50M - HS50 M Amplifier and Power Circuit Diagram; Amplifier and Output Stage Circuitry; Power Transformer and AC Inlet Circuitry

HS80M/HS50M
6
2
ABCDEFGH I J
1
3
4
5
7
6
1
2
3
4
5
6
7
■ HS50M OVERALL CIRCUIT DIAGRAM 2/2 (AMP, TRANS, AC INLET)
REGULATOR +15V
REGULATOR -15V
LIMITER
POWER AMP
POWER AMP
POWER TRANSFORMER
POWER INDICATOR
TRANS
AC INLET
AMP
to INPUT
CB101 (to Page 6 I4)
POWER
SWITCH


Note: See parts list for details of circuit board component parts.
注： シートの部品詳細はパーツリストをご参照下さい。
TWEETER
WOOFER
RED
BLACK
BLUE
YELLOW
Distination
J
U, T
H, A, K
B
O
AC Cord
WG261700
WG261800
WG262000
WG261900
WG262200
Distination
J, U, T
H, B, A, K, O
F801
WG265700
WG265800
1A 100 V, 120 V
400 mA 230V
Distination
J
U, T
H, B, O, K
A
Transformer
WG263700
WG263800
WG263900
WG264000
• LM3886TF-2 (X7244A00)
POWER AMP
AMP IC601, 602
Distination
J, U, T
H, B, A, K, O
AC INLET
WG262800
WG263000
