HS80M/HS50M
7
■ CIRCUIT BOARD LAYOUT （ユニットレイアウト）
• HS80M
• HS50M
INPUT
AC INLET
TRANS
AMP
(LF 2/4)
(LF 3/4)
(LF 1/4)
(LF 4/4)
INPUT
AC INLET
TRANS
AMP
(LF 2/4)
(LF 3/4)
(LF 1/4)
(LF 4/4)
