Yamaha HTR-6060 Service Manual

13
RX-V661/HTR-6060/DSP-AX761
RX-V661/HTR-6060/
DSP-AX761
D E GFC
3
61 2 45 7 0 BA8 9 1
2
3
4
5
6
7
8
9
0
A
B
C
D
E
F
G
POWER TRANSFORMER
FUNCTION (5) P.C.B.
FUNCTION (3) P.C.B.
VIDEO P.C.B.
FUNCTION (2) P.C.B.
FUNCTION (4) P.C.B. (R, L models)
HDMI P.C.B.
MAIN (1) P.C.B.
MAIN (2) P.C.B.
FUNCTION (1) P.C.B.
DSP P.C.B.
Tuner (U, C, R, T, K, A, G, E, L, J models)
OPERATION (2) P.C.B.
OPERATION (5) P.C.B. (RX-V661: U, C, R, T, K, A, G, E,
L models / HTR-6060: G model)
OPERATION (3) P.C.B.
OPERATION (1) P.C.B.
OPERATION (4) P.C.B.
■ INTERNAL VIEW
• Top view
• Front view

Yamaha HTR-6060 Specifications

General

Audio Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Atmos	No
DTS:X	No
Built-in Bluetooth	No
Wi-Fi	No
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	100 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Presets	40
Digital Audio Inputs	2 Optical, 1 Coaxial
Digital Audio Output	1 Optical
Weight	24.7 lbs (11.2 kg)
THD	0.06%
Frequency Response	10Hz - 100kHz
Surround Sound	Dolby Digital, DTS
Dimensions (W x H x D)	435 x 173 x 389 mm
Streaming Services	No
