Panel Controls
10
These are the fundamental controls of the DX200 — for
changing modes, adjusting values, exiting from func-
tions, and so on.
Display and indicators
[SONG] ...................................Tips 8, 63
[PATTERN] .....................................Tip 1
[DATA] knob .............................Tips 2, 69
[SHOW VALUE] ....................... Tips 21, 22
[STORE]........................... Tips 48, 61, 68
[EXIT]......................................... Tip 23
For the most part, these buttons are related to the Pat-
terns — especially for controlling record and playback
operations.
Start/Stop ......................................Tip 1
[TAP] ...........................................Tip 5
Record ........................Tips 49, 51, 59, 60
[SWING] .................................Tips 6, 27
[REVERSE]...............................Tips 4, 25
[SHIFT]................................. Tips 69, 70
[OCT <<] ............................... Tips 10, 63
[OCT >>] ............................... Tips 10, 63
[KEYBOARD] ............................Tips 9, 26
[PATTERN SELECT]........... Tips 3, 31, 78, 79
[SYNTH TRACK] ............................ Tip 28
[RHYTHM TRACK] .......................... Tip 28
These controls are for editing and changing the sound of
the Voices.
[SCENE] ................................Tips 13, 14
[FREE EG] ..............................Tips 49, 50
[VOLUME]
[LFO] ................................ Tips 32 — 35
[EG] .................................. Tips 36 — 39
[DIST] ........................................Tip 17
[COMMON] .................................. Tip 47
[ALGORITHM] ............................... Tip 41
[MODULATOR] .............................. Tip 42
[NOISE OSC]................................. Tip 46
[EFFECT/MIXER] ................. Tips 15, 16, 30
[PORTAMENTO] ............................. Tip 40
[HARMONIC] ................................ Tip 42
[FM DEPTH] ................................. Tip 43
[DECAY] ...................................... Tip 44
[NOISE LEVEL] ..............................Tip 45
[VCF] ................................ Tips 18 — 20
The Keyboard section has several main uses:
• Playing the Voices................... Tips 9, 86
• Selecting Patterns.......Tips 2, 3, 31, 78, 79
• Controlling the Sequence Steps
..................................... Tips 29, 59, 60
• Selecting functions and operations
. Tips 28, 52 – 58, 60, 62, 66, 67, 80, 81, 86, 91 – 93
Main
Control
Voice
Keyboard
