135
MIDI Data Format
Appendix
1 00...01 Step Seq Mute 9 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 10 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 11 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 12 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 13 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 14 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 15 MuteOFF(0),MuteON(1) MuteOFF(0)
1 00...01 Step Seq Mute 16 MuteOFF(0),MuteON(1) MuteOFF(0)
TOTAL SIZE 66
nn = User Pattern Number ( 0 - 7F )
*1 : MSB bit 2-0 -> bit 9-7
LSB bit 6 -0 -> bit 6-0
*2 : This should be transmitted after sending Step Seq Gate Time LSB n.
<2-1>
Parameter Group Number
<2-2>
MIDI Parameter Change table ( DX Voice Parameter - VCED format )
Parameter Group# Parameter# Size Data Parameter Description Default
g h OP6 OP5 OP4 OP3 OP2 OP1
(H) (H) (H) (H) (H) (H) (H) (H) (H) (H) (H)
00 00 00 15 2A 3F 54 69 1 00 - 63 EG RATE1 0 ... 99 63
00 01 16 2B 40 55 6A 1 00 - 63 EG RATE2 0 ... 99 63
00 02 17 2C 41 56 6B 1 00 - 63 EG RATE3 0 ... 99 63
00 03 18 2D 42 57 6C 1 00 - 63 EG RATE4 0 ... 99 63
00 04 19 2E 43 58 6D 1 00 - 63 EG LELEL1 0 ... 99 63
00 05 1A 2F 44 59 6E 1 00 - 63 EG LELEL2 0 ... 99 63
00 06 1B 30 45 5A 6F 1 00 - 63 EG LELEL3 0 ... 99 63
00 07 1C 31 46 5B 70 1 00 - 63 EG LELEL4 0 ... 99 00
00 08 1D 32 47 5C 71 1 00 - 63 BREAK POINT A-1 ... C8 27
00 09 1E 33 48 5D 72 1 00 - 63 LEFT DEPTH 0 ... 99 00
00 0A 1F 34 49 5E 73 1 00 - 63 RIGHT DEPTH 0 ... 99 00
00 0B 20 35 4A 5F 74 1 00 - 03 LEFT CURVE -lin,-exp,+exp,+lin 00
00 0C 21 36 4B 60 75 1 00 - 03 RIGHT CURVE -lin,-exp,+exp,+lin 00
00 0D 22 37 4C 61 76 1 00 - 07 RATE SCALING 0 ... 7 00
00 0E 23 38 4D 62 77 1 00 - 03 AMPLITUDE MODULATION SENSITIVITY 0 ... 3 00
00 0F 24 39 4E 63 78 1 00 - 07 TOUCH SENSITIVITY 0 ... 7 00
00 10 25 3A 4F 64 79 1 00 - 63 TOTAL LEVEL 0 ... 99 OP1=99,otherOP=0
00 11 26 3B 50 65 7A 1 00 - 01 FREQUENCY MODE ratio,fixed 00
00 12 27 3C 51 66 7B 1 00 - 1F FREQUENCY COURSE 0 ... 31 01
00 13 28 3D 52 67 7C 1 00 - 63 FREQUENCY FINE 0 ... 99 00
00 14 29 3E 53 68 7D 1 00 - 0E DETUNE -7 ... 0 ... +7 07
00 7E 1 00 - 63 PEG RATE1 0 ... 99 63
00 7F 1 00 - 63 PEG RATE2 0 ... 99 63
01 00 1 00 - 63 PEG RATE3 0 ... 99 63
01 01 1 00 - 63 PEG RATE4 0 ... 99 63
01 02 1 00 - 63 PEG LEVEL1 0 ... 99 32
01 03 1 00 - 63 PEG LEVEL2 0 ... 99 32
01 04 1 00 - 63 PEG LEVEL3 0 ... 99 32
01 05 1 00 - 63 PEG LEVEL4 0 ... 99 32
01 06 1 00 - 1F ALGORITHM SELECTOR 1 ... 32 00
01 07 1 00 - 07 FEEDBACK LEVEL 0 ... 7 00
01 08 1 00 - 01 OSC PHASE INIT off,on 01
01 09 1 00 - 63 LFO SPEED 0 ... 99 23
01 0A 1 00 - 63 LFO DELAY TIME 0 ... 99 00
01 0B 1 00 - 63 PITCH MODULATION DEPTH 0 ... 99 00
01 0C 1 00 - 63 AMPLITUDE MODULATION DEPTH 0 ... 99 00
01 0D 1 00 - 01 LFO KEY SYNC off,on 01
01 0E 1 00 - 05 LFO WAVE triangle,sawdown,sawup,square, 00
sine,s/hold
01 0F 1 00 - 07 LFO PITCH MODULATION SENSITIVITY 0 ... 7 03
01 10 1 00 - 30 TRANSPOSE C1 ... C5 18
01 11 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 'I'
01 12 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 'n'
01 13 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 'i'
01 14 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 't'
01 15 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) ' '
01 16 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 'P'
01 17 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 't'
01 18 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) 'n'
01 19 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) ' '
01 1A 1 20 - 7F VOICE NAME 32 ... 127 (ASCII CHARACTER) ' '
TOTAL SIZE 9B
01 1B 1 00 - 3F OPERATOR ENABLE Bit5:OP1,Bit4:OP2,Bit3:OP3, 3F
Bit2:OP4,Bit1:OP5,Bit0:OP6 off,on
Parameter
parameter#Group No.
Description
gh
00 00 VCED(Voice Edit Buffer) 0 ... 127
00 01 VCED(Voice Edit Buffer) 0 ... 28
06 00 ACED(Additional Edit Buffer) 0 ... 73
To Next Page
