DESCRIPTION
2-2
2
EAU10420
Right view
12
1213 10 9 8
3,4 5 6 7
11
1. Tail/brake light (page 6-31)
2. Rear brake fluid reservoir (page 6-20)
3. Owner’s tool kit (page 6-2)
4. Battery (page 6-27)
5. Air filter element (page 6-14)
6. Fuel tank cap (page 3-13)
7. Front brake fluid reservoir (page 6-20)
8. Brake pedal (page 3-12)
9. Rear brake light switch (page 6-19)
10.Engine oil filter cartridge (page 6-10)
11.Engine oil drain bolt (page 6-10)
12.Coolant reservoir (page 6-13)
13.Shock absorber assembly spring preload adjusting ring (page 3-17)
