MOX6/MOX8 Reference Manual
Remote Mode
Remote display
Remote Control Assignments
138
7 Buttons for the Memory 1 – 6
Determines which Memory is assigned to the [SF1] – [SF6] buttons.
8 Memory name
Determines the name for the Memory specified by parameter (7) above; maximum 16 characters in length.
9 Load
Loads the file to which the settings of the MOX6/MOX8 Extension Setup window are stored.
) Save
Settings other than the Option window in the MOX6/MOX8 Extension Setup window are stored as a file.
! Reset Memory 1/2/3/4/5/6
Clicking these buttons restores the default settings of the selected Memory to the [SF1] – [SF6] buttons.
Restoring the default data by clicking the Reset Memory button overwrites the registered functions for the [SF1] – [SF6] buttons
to the selected Memory.
SF Assign (Quick) window
This window assigns functions to the [SF1] – [SF6] buttons. The setting menu is the same as the SF Assign window. In
SF Assign (Quick) window, you can assign the functions with the [SF1] – [SF6] buttons shown on the window.
Option window
This window determines the following settings.
• Determines whether the dialog for the Audio Driver settings is shown or not when starting Cubase.
• When moving the project cursor of the Cubase by operating the jog dial, this determines whether the cursor stops
immediately when jog operation is stopped (on), or slows down gradually before stopping (off).
To Next Page
