Yamaha MOX8 Reference Manual

PERF SONG PATTERN MIX MASTER REMOTE UTILITY QUICK SET FILEVOICE
MOX6/MOX8 Reference Manual
Utility Mode
[F1] GENERAL
[F2] VOICE
[F2] SEQ
[F3] VCE A/D
[F4] CTL ASN
[F5] USB I/O
[F6] MIDI
Utility Job
141
Utility Mode
In the Utility mode, you can set parameters that apply to the entire system of the MOX6/MOX8. This mode is actually a
sub-mode of the Voice/Performance/Song/Pattern mode. Press the [UTILITY] button in each mode to enter the Utility
mode and press the [EXIT] button after making settings to go back to the previous mode.
[SF1] TG (Tone Generator)
From this section, you can make overall settings for the internal tone generator. The settings here only affect the internal
tone generator block. The MIDI output will not be affected.
Volume
Determines the overall volume of the instrument.
Settings: 0 – 127
NoteShift
Determines the amount (in semitones) by which the pitch of all notes is shifted.
Settings: -24 – +0 – +24
Tune
Determines the fine tuning of the MOX6/MOX8’s overall sound (in 0.1 cent steps).
Settings: -102.4 – +0.0 – +102.3
SystemFxOn/OffBtn Chorus (System Effect On/Off Button Chorus)
Turns the Chorus Effect on/off.
Settings: off, on
SystemFxOn/OffBtn Reverb (System Effect On/Off Button Reverb)
Turns the Reverb Effect on/off.
Settings: off, on
[SF2] OUTPUT
L&R Gain
Determines the output gain of the OUTPUT [L/MONO] and [R] jacks.
Settings: 0dB, +6dB
USB 1/2 Gain
USB 3/4 Gain
Determines the output gain of the USB 1/2 channels or USB 3/4 channels.
Settings: 0dB, +6dB
[SF3] KBD (Keyboard)
From this display you can set the keyboard-related parameters. The settings here affect the MIDI messages generated
by playing the keyboard.
Octave
Determines the amount in octaves by which the range of the keyboard is shifted up or down. This parameter is linked
with the OCTAVE [-]/[+] buttons on the panel.
Settings: -3 – +0 – +3
Transpose
This parameter is used to transpose the current zone in units of one semitone.
Settings: -11 – +0 – +11
NOTE If you transpose beyond the note range limits (C -2 and G8), notes in the adjacent octaves will be used.
Operation
Press the [UTILITY] button.
[F1] GENERAL

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
