MOX6/MOX8 Reference Manual
Voice Mode
Voice Play
[F1] PLAY
[F3] PORTA
[F4] EG
[F5] ARP ED
[F6] EFFECT
Arpeggio Edit
[F2] TYPE
[F3] MAIN
[F4] LIMIT
[F5] PLAY FX
Normal Voice Edit
Common Edit
[F1] GENERAL
[F2] OUTPUT
[F3] EQ
[F4] CTL SET
[F5] LFO
[F6] EFFECT
Element Edit
[F1] OSC
[F2] PITCH
[F3] FILTER
[F4] AMP
[F5] LFO
[F6] EQ
Drum Voice Edit
Common Edit
[F1] GENERAL
[F2] OUTPUT
[F3] EQ
[F4] CTL SET
[F6] EFFECT
Key Edit
[F1] OSC
[F2] PITCH
[F3] FILTER
[F4] AMP
[F6] EQ
Voice Job
[F1] INIT
[F2] RECALL
[F3] COPY
[F4] BULK
Supplementary Information
54
 Functions of Knobs 1 – 8
This section explains the functions assigned to Knobs 1 – 8 in the Voice mode. For instructions, see the Owner’s Manual.
When the [TONE 1] lamp is turned on:
Knob 1 CUTOFF [VOICE]  [F4] EG  FEG “CUTOF” page 26
Knob 2 RESONANCE [VOICE]  [F4] EG  FEG “RESO” page 26
Knob 3 FEG DEPTH [VOICE]  [F4] EG  FEG “DEPTH” page 26
Knob 4 PORTAMENTO [VOICE]  [F3] PORTA  “PortaTime” page 26
When the [TONE 2] lamp is turned on:
Knob 1 ATTACK [VOICE]  [F4] EG  AEG “ATK” page 26
Knob 2 DECAY [VOICE]  [F4] EG  AEG “DCY” page 26
Knob 3 SUSTAIN [VOICE]  [F4] EG  AEG “SUS” page 26
Knob 4 RELEASE [VOICE]  [F4] EG  AEG “REL” page 26
When the [TONE 3] lamp is turned on:
Knob 1 VOLUME [VOICE]  [EDIT]  [COMMON]  [F2] OUTPUT  “Volume” page 31
Knob 2 PAN [VOICE]  [EDIT]  [COMMON]  [F2] OUTPUT  “Pan” page 31
Knob 3 ASSIGN 1 [VOICE]  [EDIT]  [COMMON]  [F4] CTL SET  function that is set in “Dest” when
“Source” is set to ”AS1”/”AS2”
page 32
Knob 4 ASSIGN 2
When the [EQ] lamp is turned on:
Knob 5 LOW [VOICE]  [EDIT]  [COMMON]  [F3] EQ  “LOW GAIN” page 32
Knob 6 MID F [VOICE]  [EDIT]  [COMMON]  [F3] EQ  “MID FREQ”
Knob 7 MID [VOICE]  [EDIT]  [COMMON]  [F3] EQ  “MID GAIN”
Knob 8 HIGH [VOICE]  [EDIT]  [COMMON]  [F3] EQ  “HIGH GAIN”
When the [EFFECT] lamp is turned on:
Knob 5 CHO PRESET [VOICE]  [F6] EFFECT  [SF4] CHORUS  “Preset” page 36
Knob 6 CHO SEND [VOICE]  [F6] EFFECT  [SF1] CONNECT  “Chorus Send” page 35
Knob 7 REV PRESET [VOICE]  [F6] EFFECT  [SF5] REVERB  “Preset” page 36
Knob 8 REV SEND [VOICE]  [F6] EFFECT  [SF1] CONNECT  “Reverb Send” page 35
When the [ARP] lamp is turned on:
Knob 5 GATE TIME [VOICE]  ARP [EDIT]  [F5] PLY FX  “GateTimeRate” page 28
Knob 6 OCT RANGE [VOICE]  ARP [EDIT]  [F5] PLY FX  “OctaveRange” page 29
Knob 7 UNITMULTIPLY [VOICE]  ARP [EDIT]  [F5] PLY FX  “UnitMultiply” page 28
Knob 8 TEMPO [VOICE]  ARP [EDIT]  [F3] MAIN  “Tempo” page 27

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
