Yamaha MOX8 Data List

MOX6/MOX8 Data List
108
MIDI Data Table
TOTAL SIZE = 20 14 (HEX)
TOTAL SIZE = 38 26 (HEX)
TOTAL SIZE = 8 08 (HEX)
n = part number 00 – 00
TOTAL SIZE = 10 0A (HEX)
n = step number 00 – 05
TOTAL SIZE = 16 10 (HEX)
n = config number 00 – 05
TOTAL SIZE = 16 10 (HEX)
n = config number 00 – 05
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
00 20 00 1 34 – 4C EQ Low Gain -12 – +12 [dB] 40 For the Voice
Mode
01 1 04 – 28 EQ Low Frequency 32 – 2000 [Hz] 0C When setting the
EQ shape
peaking type, the
range is 63Hz –
2.0kHz.
02 1 01 – 78 EQ Low Q 0.1 – 12.0 07 When setting the
EQ shape
shelving type, this
is not available.
03 1 00 – 01 EQ Low Shape shelv, peak 00
04 1 34 – 4C EQ Low-Mid Gain -12 – +12 [dB] 40
05 1 0E – 36 EQ Low-Mid Frequency 100 – 10.0 [kHz] 14
06 1 01 – 78 EQ Low-Mid Q 0.1 – 12.0 07
07 1 reserved
08 1 34 – 4C EQ Mid Gain -12 – +12 [dB] 40
09 1 0E – 36 EQ Mid Frequency 100 – 10.0 [kHz] 1C
0A 1 01 – 78 EQ Mid Q 0.1 – 12.0 07
0B 1 reserved
0C 1 34 – 4C EQ High-Mid Gain -12 – +12 [dB] 40
0D 1 0E – 36 EQ High-Mid Frequency 100 – 10.0 [kHz] 2C
0E 1 01 – 78 EQ High-Mid Q 0.1 – 12.0 07
0F 1 reserved
10 1 34 – 4C EQ High Gain -12 – +12 [dB] 40
11 1 1C – 3A EQ High Frequency 0.5 – 16.0 [kHz] 34
12 1 01 – 78 EQ High Q 0.1 – 12.0 07 When setting the
EQ shape
shelving type, this
is not available.
13 1 00 – 01 EQ High Shape shelv, peak 00
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
00 21 00 2 00 – 7F
00 – 7F
Master Effect Type Refer to the “Effect
Type List.”
08
20
For the
Voice
Mode
Multi Band
Comp
02 1 00 – 7F Preset Number 00 Basic
03 1 reserved
04 2 00 – 7F
00 – 7F
Master Effect Parameter 1 Refer to the “Effect
Parameter List.”
Init value for Multi
Band Comp / Basic
06 2 00 – 7F
00 – 7F
Master Effect Parameter 2 : Init value for Multi
Band Comp / Basic
08 2 00 – 7F
00 – 7F
Master Effect Parameter 3 : Init value for Multi
Band Comp / Basic
0A 2 00 – 7F
00 – 7F
Master Effect Parameter 4 : Init value for Multi
Band Comp / Basic
0C 2 00 – 7F
00 – 7F
Master Effect Parameter 5 : Init value for Multi
Band Comp / Basic
0E 2 00 – 7F
00 – 7F
Master Effect Parameter 6 : Init value for Multi
Band Comp / Basic
10 2 00 – 7F
00 – 7F
Master Effect Parameter 7 : Init value for Multi
Band Comp / Basic
12 2 00 – 7F
00 – 7F
Master Effect Parameter 8 : Init value for Multi
Band Comp / Basic
14 2 00 – 7F
00 – 7F
Master Effect Parameter 9 : Init value for Multi
Band Comp / Basic
16 2 00 – 7F
00 – 7F
Master Effect Parameter 10 : Init value for Multi
Band Comp / Basic
18 2 00 – 7F
00 – 7F
Master Effect Parameter 11 : Init value for Multi
Band Comp / Basic
1A 2 00 – 7F
00 – 7F
Master Effect Parameter 12 : Init value for Multi
Band Comp / Basic
1C 2 00 – 7F
00 – 7F
Master Effect Parameter 13 : Init value for Multi
Band Comp / Basic
1E 2 00 – 7F
00 – 7F
Master Effect Parameter 14 : Init value for Multi
Band Comp / Basic
20 2 00 – 7F
00 – 7F
Master Effect Parameter 15 : Init value for Multi
Band Comp / Basic
22 2 00 – 7F
00 – 7F
Master Effect Parameter 16 : Init value for Multi
Band Comp / Basic
24 1 00 – 01 Master Effect Switch off, on 00
25 1 reserved
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
00 4n 00 1 00 – 03 Audio Input Mode L mono, R mono,
L+R mono,
stereo
03 Audio In Part
(A/D)
01 1 00 – 7F Audio Input Part Volume 0 – 127 64
02 1 01 – 7F Audio Input Part Pan L63 – C – R63 40
03 1 00 – 7F Audio Input Part Reverb
Send
0 – 127 0C
04 1 00 – 7F Audio Input Part Chorus
Send
0 – 127 00
05 1 reserved
06 1 00 – 7F Audio Input Part Dry Level 0 – 127 7F
07 1 reserved
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
00 5n 00 1 00, 20 – 7E Quick Setup Name 1 0, 32..126 (ASCII) 20
01 1 00, 20 – 7E Quick Setup Name 2 0, 32..126 (ASCII) 20
02 1 00, 20 – 7E Quick Setup Name 3 0, 32..126 (ASCII) 20
03 1 00, 20 – 7E Quick Setup Name 4 0, 32..126 (ASCII) 20
04 1 00, 20 – 7E Quick Setup Name 5 0, 32..126 (ASCII) 20
05 1 00, 20 – 7E Quick Setup Name 6 0, 32..126 (ASCII) 20
06 1 00, 20 – 7E Quick Setup Name 7 0, 32..126 (ASCII) 20
07 1 00, 20 – 7E Quick Setup Name 8 0, 32..126 (ASCII) 20
08 1 00 – 06 Config Number Audio ---, config 1 – 6
09 1 00 – 06 Config Number MIDI ---, config 1 – 6
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
00 6n 00 1 00 – 02 Audio Connection
Mode
VST Mode,
2 Stereo Rec Mode,
1 Stereo Rec Mode
01 1 00 – 01 Direct Monitor Switch
A/D In/Part
off, on For the audio
signal which
is output via
“USB 1/2.”
02 1 00 – 01 Direct Monitor Switch
Part
off, on For the audio
signal which
is output via
“USB 3/4.”
03 1 reserved
04 1 reserved
05 1 reserved
06 1 reserved
07 1 reserved
08 1 reserved
09 1 reserved
0A 1 reserved
0B 1 reserved
0C 1 reserved
0D 1 reserved
0E 1 reserved
0F 1 reserved
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
00 7n 00 1 00 – 01 Local Switch off, on
01 1 00 – 03 Midi Sync internal, external,
auto, MTC
02 1 00 – 01 Midi Clock Out off, on
03 1 00 – 01 Track Internal Switch all off, all on For SEQ
04 1 00 – 01 Track External Switch all off, all on For SEQ
05 1 00 – 01 ARP MIDI Out Switch all off, all on
06 1 00 – 01 Keyboard Transmit
Channel
1 – 16, off
07 1 reserved
08 1 reserved
09 1 reserved
0A 1 reserved
0B 1 reserved
0C 1 reserved
0D 1 reserved
0E 1 reserved
0F 1 reserved

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
