Yamaha MOX8 Data List

MOX6/MOX8 Data List
109
MIDI Data Table
TOTAL SIZE = 32 20 (HEX)
TOTAL SIZE = 16 10 (HEX)
nn = zone number 00 – 03
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
33 00 00 1 00, 20 – 7E Master Name 1 0, 32..126 (ASCII) I
01 1 00, 20 – 7E Master Name 2 0, 32..126 (ASCII) n
02 1 00, 20 – 7E Master Name 3 0, 32..126 (ASCII) i
03 1 00, 20 – 7E Master Name 4 0, 32..126 (ASCII) t
04 1 00, 20 – 7E Master Name 5 0, 32..126 (ASCII) i
05 1 00, 20 – 7E Master Name 6 0, 32..126 (ASCII) a
06 1 00, 20 – 7E Master Name 7 0, 32..126 (ASCII) l
07 1 00, 20 – 7E Master Name 8 0, 32..126 (ASCII) i
08 1 00, 20 – 7E Master Name 9 0, 32..126 (ASCII) z
09 1 00, 20 – 7E Master Name 10 0, 32..126 (ASCII) e
0A 1 00, 20 – 7E Master Name 11 0, 32..126 (ASCII) d
0B 1 00, 20 – 7E Master Name 12 0, 32..126 (ASCII)
0C 1 00, 20 – 7E Master Name 13 0, 32..126 (ASCII) M
0D 1 00, 20 – 7E Master Name 14 0, 32..126 (ASCII) a
0E 1 00, 20 – 7E Master Name 15 0, 32..126 (ASCII) s
0F 1 00, 20 – 7E Master Name 16 0, 32..126 (ASCII) t
10 1 00, 20 – 7E Master Name 17 0, 32..126 (ASCII) e
11 1 00, 20 – 7E Master Name 18 0, 32..126 (ASCII) r
12 1 00, 20 – 7E Master Name 19 0, 32..126 (ASCII)
13 1 00, 20 – 7E Master Name 20 0, 32..126 (ASCII)
14 1 reserved
15 1 reserved
16 1 reserved
17 1 reserved
18 1 reserved
19 1 00 – 03 Mode Change 0=Voice,
1=Performance,
2=Pattern, 3=Song
00
1A 1 00 – 7F Bank MSB for Voice/Perf
Mode
0..127 3F
1B 1 00 – 7F Bank LSB for Voice/Perf
Mode
0..127 00
1C 1 00 – 7F Program Number 1..128 00
1D 1 00 – 01 Zone on/off off, on 00
1E 1 00 – 22 Knob Function Select bit0-3 KnobUp:
0=Tone1, 1=Tone2,
2=Tone3
bit4-7 KnobLo: 0=EQ ,
1=Fx, 2=Arp
00
1F 1 00 – 01 Knob Zone on/off off, on 01 This is
available
only when
“Zone on/
off” is set
to on.
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
32 nn 00 1 00 – 3F Transmit Channel, MIDI/TG
Switch
bit6: reserved
bit5: TG off, on
bit4: MIDI off, on
bit0-3: Ch1..16
Zone1:
30
Other:
00
01 1 3D – 43 Octave -3..+3 40
02 1 35 – 4B Transpose -11..+11 (semitones) 40
03 1 00 – 7F Note Limit Low C-2..G8 00
04 1 00 – 7F Note Limit High C-2..G8 7F
05 1 reserved 7F
06 1 00 – 7F MIDI Volume 0..127 64
07 1 00 – 7F MIDI Pan 0..127 40
08 1 00 – 7F MIDI Bank MSB 0..127 00
09 1 00 – 7F MIDI Bank LSB 0..127 00
0A 1 00 – 7F MIDI Program Number 1..128 00
0B 1 00 – 1F reserved
Transmit Program Change for
MIDI
Transmit Bank Select for MIDI
reserved
Transmit Program Change for
TG
Transmit Bank Select for TG
bit6-5: reserved
bit4: off, on Program
Change
bit3: off, on Bank Select
bit2: reserved
bit1: off, on Program
Change
bit0: off, on Bank Select
00
0C 1 00 – 7F Transmit PB
reserved
Transmit Assignable Switch 2
Transmit Assignable Switch 1
Transmit Sustain
Transmit Pan
Transmit Volume/Expression
bit6: off, on PB
bit5: reserved
bit4: off, on Assignable
Switch 2
bit3: off, on Assignable
Switch 1
bit2: off, on Sustain
bit1: off, on Pan
bit0: off, on Volume/
Expression
67
Ctrl#7,
11
0D 1 00 – 7F Transmit Assignable Knob
reserved
Transmit MW
Transmit BC
Transmit FC1
Transmit FS
reserved
bit6: off, on Assignable
Knob
bit5: reserved
bit4: off, on MW
bit3: off, on BC
bit2: off, on FC1
bit1: off, on FS
bit0: reserved
7F
0E 1 00 – 5F Control Upper Knob Control
Number
off, 1 – 95 07
0F 1 00 – 5F Control Lower Knob Control
Number
off, 1 – 95 0A
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
MIDI PARAMETER CHANGE TABLE
(MASTER KEYBOARD)

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
