Yamaha MOX8 Data List

MOX6/MOX8 Data List
110
MIDI Data Table
TOTAL SIZE = 80 50 (HEX)
TOTAL SIZE = 14 0E (HEX)
TOTAL SIZE = 38 26 (HEX)
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
30 00 00 1 00, 20 – 7E Performance Name 1 0, 32..126 (ASCII) I
01 1 00, 20 – 7E Performance Name 2 0, 32..126 (ASCII) n
02 1 00, 20 – 7E Performance Name 3 0, 32..126 (ASCII) i
03 1 00, 20 – 7E Performance Name 4 0, 32..126 (ASCII) t
04 1 00, 20 – 7E Performance Name 5 0, 32..126 (ASCII) i
05 1 00, 20 – 7E Performance Name 6 0, 32..126 (ASCII) a
06 1 00, 20 – 7E Performance Name 7 0, 32..126 (ASCII) l
07 1 00, 20 – 7E Performance Name 8 0, 32..126 (ASCII) i
08 1 00, 20 – 7E Performance Name 9 0, 32..126 (ASCII) z
09 1 00, 20 – 7E Performance Name 10 0, 32..126 (ASCII) e
0A 1 00, 20 – 7E Performance Name 11 0, 32..126 (ASCII) d
0B 1 00, 20 – 7E Performance Name 12 0, 32..126 (ASCII) P
0C 1 00, 20 – 7E Performance Name 13 0, 32..126 (ASCII) e
0D 1 00, 20 – 7E Performance Name 14 0, 32..126 (ASCII) r
0E 1 00, 20 – 7E Performance Name 15 0, 32..126 (ASCII) f
0F 1 00, 20 – 7E Performance Name 16 0, 32..126 (ASCII) o
10 1 00, 20 – 7E Performance Name 17 0, 32..126 (ASCII) r
11 1 00, 20 – 7E Performance Name 18 0, 32..126 (ASCII) m
12 1 00, 20 – 7E Performance Name 19 0, 32..126 (ASCII)
13 1 00, 20 – 7E Performance Name 20 0, 32..126 (ASCII)
14 1 reserved
15 1 reserved
16 1 reserved
17 1 reserved
18 1 00 – 07 Performance Category
(Main)
0..7 07
(NoAsg)
19 1 00 – 0B Performance Category
(Sub)
0..11 00 (--)
1A 1 reserved
1B 1 reserved
1C 1 reserved
1D 1 reserved
30 00 1E 1 00 – 22 Knob Function Select bit0-3 KnobUp:
0=Tone1, 1=Tone2,
2=Tone3
bit4-7 KnobLo: 0=EQ,
1=Fx, 2=Arp
00
1F 1 01 – 7F Pan L63..C..R63 40
20 1 reserved
21 1 00 – 7F AEG Attack Time -64..+63 40
22 1 00 – 7F AEG Decay Time -64..+63 40
23 1 00 – 7F AEG Sustain Level -64..+63 40
24 1 00 – 7F AEG Release Time -64..+63 40
25 1 00 – 7F FEG Attack Time -64..+63 40
26 1 00 – 7F FEG Decay Time -64..+63 40
27 1 reserved
28 1 00 – 7F FEG Release Time -64..+63 40
29 1 00 – 7F FEG Depth -64..+63 40
2A 1 00 – 7F Cutoff Frequency -64..+63 40
2B 1 00 – 7F Resonance -64..+63 40
2C 1 reserved
2D 1 reserved
2E 1 00 – 7F EQ Low Frequency -64..+63 40
2F 1 00 – 7F EQ Low Gain -64..+63 40
30 1 reserved
31 1 00 – 7F EQ Mid Frequency -64..+63 40
32 1 00 – 7F EQ Mid Gain -64..+63 40
33 1 00 – 7F EQ Mid Q -64..+63 40
34 1 reserved
35 1 00 – 7F EQ High Frequency -64..+63 40
36 1 00 – 7F EQ High Gain -64..+63 40
37 1 reserved
38 1 00 – 7F Volume 0..127 7F
39 1 00 – 7F Portamento Time -64..+63 40
3A 1 00 – 01 Portamento Switch off, on 01
3B 1 00 – 7F Reverb Send 0..127 7F
3C 1 00 – 7F Chorus Send 0..127 7F
30 00 3D 1 reserved
3E 1 reserved
3F 1 00 – 01 Assignable Switch 1 Mode momentary, latch 01
40 1 00 – 01 Assignable Switch 2 Mode momentary, latch 01
41 1 reserved
42 1 01 – 7F Split Point C#-2...G8 3C
43 1 00 – 01 Split Switch off, on 00
44 1 reserved
45 1 reserved
46 1 reserved
47 1 reserved
48 1 reserved
49 1 reserved
4A 1 reserved
4B 1 01 – 02 A/D Input Insertion
Connect Type
ins A>B, ins B>A 01
4C 4 00 – 00
00 – 20
00 – 00
00 – 0F
Insertion Part Sw 1st bit6-0: reserved
2nd bit6: reserved
2nd bit5: off, on A/D
Part
2nd bit4-0: reserved
3rd bit6-0: reserved
4th bit6-4: reserved
4th bit3: off, on Part 4
4th bit2: off, on Part 3
4th bit1: off, on Part 2
4th bit0: off, on Part 1
00
00
00
07
Up to three
parts can
be turned
on simulta-
neously.
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
30 30 00 1 00 – 05 ARP SF Select SF1 ~ SF6 00
01 1 reserved
02 2 00 – 02
05 – 2C
ARP Tempo 5..300 00 5A
04 1 00 – 01 ARP Common Switch off, on 00
05 1 00 – 07 ARP Sync Quantize Value off, 32th, 16th_Triplet,
16th, 8th_Triplet, 8th,
4th_Triplet, 4th
00
06 2 00 – 01
1C – 64
ARP Quantize Strength
Offset
-100 … +100 00 80
08 2 00 – 01
1C – 64
ARP Gate Time Rate
Offset
-100 … +100 01 00
0A 2 00 – 01
1C – 64
ARP Velocity Rate Offset -100 … +100 01 00
0C 2 00 – 01
08 – 78
ARP Swing Offset -120 … +120 01 00
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
30 01 00 2 00 – 7F
00 – 7F
Reverb Type Refer to the “Effect
Type List.”
01 00 Rev-X Hall
02 1 00 – 7F Preset Number 00 Basic
03 1 reserved
04 2 00 – 7F
00 – 7F
Reverb Parameter 1 Refer to the “Effect
Parameter List.”
Init value for Rev-X
Hall / Basic
06 2 00 – 7F
00 – 7F
Reverb Parameter 2 : Init value for Rev-X
Hall / Basic
08 2 00 – 7F
00 – 7F
Reverb Parameter 3 : Init value for Rev-X
Hall / Basic
0A 2 00 – 7F
00 – 7F
Reverb Parameter 4 : Init value for Rev-X
Hall / Basic
0C 2 00 – 7F
00 – 7F
Reverb Parameter 5 : Init value for Rev-X
Hall / Basic
0E 2 00 – 7F
00 – 7F
Reverb Parameter 6 : Init value for Rev-X
Hall / Basic
10 2 00 – 7F
00 – 7F
Reverb Parameter 7 : Init value for Rev-X
Hall / Basic
12 2 00 – 7F
00 – 7F
Reverb Parameter 8 : Init value for Rev-X
Hall / Basic
14 2 00 – 7F
00 – 7F
Reverb Parameter 9 : Init value for Rev-X
Hall / Basic
16 2 00 – 7F
00 – 7F
Reverb Parameter 10 : Init value for Rev-X
Hall / Basic
18 2 00 – 7F
00 – 7F
Reverb Parameter 11 : Init value for Rev-X
Hall / Basic
1A 2 00 – 7F
00 – 7F
Reverb Parameter 12 : Init value for Rev-X
Hall / Basic
1C 2 00 – 7F
00 – 7F
Reverb Parameter 13 : Init value for Rev-X
Hall / Basic
1E 2 00 – 7F
00 – 7F
Reverb Parameter 14 : Init value for Rev-X
Hall / Basic
20 2 00 – 7F
00 – 7F
Reverb Parameter 15 : Init value for Rev-X
Hall / Basic
22 2 00 – 7F
00 – 7F
Reverb Parameter 16 : Init value for Rev-X
Hall / Basic
24 1 00 – 7F Reverb Return -∞dB…0dB…+6dB
(0…96…127)
40
25 1 01 – 7F Reverb Pan L63…C…R63 40
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
30 02 00 2 00 – 7F
00 – 7F
Chorus Type Refer to the “Effect
Type List.”
03
00
G Chorus
02 1 00 – 7F Preset Number 00 Basic
03 1 reserved
04 2 00 – 7F
00 – 7F
Chorus Parameter 1 Refer to the “Effect
Parameter List.”
Init value for G
Chorus / Basic
06 2 00 – 7F
00 – 7F
Chorus Parameter 2 : Init value for G
Chorus / Basic
08 2 00 – 7F
00 – 7F
Chorus Parameter 3 : Init value for G
Chorus / Basic
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
MIDI PARAMETER CHANGE TABLE
(PERFORMANCE COMMON)

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
