Yamaha MOXF8 Reference Manual

PERF SONG PATTERN MIX MASTER REMOTE UTILITY QUICK SET FILEVOICE
MOXF6/MOXF8 Reference Manual
Remote Mode
Remote display
Remote Control Assignments
138
Mute/Solo
You can mute or solo the currently selected Track in Cubase by
pressing the respective [MUTE]/[SOLO] button on the MOXF6/MOXF8.
Moving the cursor/ Program Change
function
The cursor [<]/[u]/[d]/[>] buttons work as cursor controls on the DAW
software. The [EXIT] button works as the <Esc> key on a computer,
while the [ENTER] button works as the <Enter> key. The [INC]/[DEC]
buttons switch the VSTi program on the DAW software. However, when
“Remote Select” is set to “Cubase,” the functions of the [INC]/[DEC]
buttons differ depending on the “ProgramChangeMode” setting of the
MOXF6/MOXF8.
When the “DAW Select” is set to something other than “Cubase,” the “ProgramChangeMode” is always set to “PC.”
Inputting a Number Directly
The number [1] – [9] buttons work as the numeric keys 1 – 9 in Cubase. The number [10] works as the numeric key 0 on
Cubase. The number [14] works as the numeric key “.”, the number [15] works as the numeric key “-”, and the number
[16] works as the numeric key “+”. You can use these number buttons when inputting a parameter number directly or
switching the tool functions in Cubase.
AI KNOB functions
The [DATA] dial of the MOXF6/MOXF8 works as the AI KNOB.
The AI KNOB can control a desired parameter within the principal
window and plug-in software in Cubase, specified via the mouse
pointer (as long as the [LOCK] button and [JOG] button are turned off).
The [CATEGORY SEARCH] button works as the [JOG] button, and the
[FAVORITE] button works as the [LOCK] button. The parameters which
are available for control by AI KNOB will differ according to the on/off
status of the [JOG] button and [LOCK] button as follows.
“ProgramChangeMode” setting Functions
remote Pressing the [INC] button selects the next program, while pressing the [DEC] button selects the
previous program.
PC Allows you to select the program corresponding to the specified number by using the [INC] /[DEC]
buttons. When specifying a program number outside the actual range of programs, the program
will not be changed. When using the VST3, pressing the [INC]/[DEC] buttons cannot change the
program.
auto When the selected Track is a MIDI Track, and the output destination of the MIDI Track is not VSTi,
the [INC]/[DEC] function is same as when “ProgramChangeMode” is set to “PC.” In other cases,
the [INC]/[DEC] function is same as when “ProgramChangeMode” is set to “remote.”
[JOG] button [LOCK] button AI KNOB functions
off off Operates the parameter specified via the mouse pointer in Cubase.
off on When you locate the mouse pointer to the desired parameter then turn the [LOCK] button on, the
AI KNOB will control the “locked” parameter regardless of the mouse pointer’s position.
on off Moves the time position of the current project. The MOXF6/MOXF8 Extension Setup window (page
136) determines whether the cursor stops immediately when jog operation is stopped (on), or
slows down gradually before stopping (off).
on on Moves the time position of the current project. Moving of the time position will not stop even if you
stop operating the AI KNOB. You can stop playback at any time by pressing the [J] (Stop) button.

Yamaha MOXF8 Specifications

General

Product type	Digital synthesizer
Product color	Black
Sound effects	Chorus, Reverberation
Tap tempo switch	Yes
Chorus effects quantity	22
Keyboard number of keys	88
Maximum polyphony (notes)	124
Reverberation effects quantity	9
Power source type	DC
Display type	LCD
Headphone outputs	1

Weight and Dimensions

Depth	405 mm
Width	1320 mm
Height	168 mm
Weight	14900 g
