MOXF6/MOXF8 Reference Manual
24
Reference
This section provides a detailed description of the parameters used to configure your MOXF6/MOXF8.
1 Indicates the selected Track.
2 Indicates the current edit status; for example, Common edit or Part edit.
3 Indicates the Voice/Performance/Song/Pattern/Master that is currently selected for editing.
4 Indicates the currently editable parameters.
5 Indicates the various displays categorized by function in tab format. Pressing the [F1] – [F6] (Function button) allows you to jump to the
display for the corresponding function.
6 Indicates the various displays categorized by the sub function in tab format (when the tab you selected in 5 above has sub functions).
Pressing the [SF1] – [SF6] (Sub Function button) allows you to jump to the display for the corresponding sub function.
Display’s Basic Configuration
About the icons
In the Reference section, the parameters marked by this icon can be changed directly via the appropriate Knob
on the panel.
12 3
4
5
6
Knob

Yamaha MOXF8 Specifications

General

Product type	Digital synthesizer
Product color	Black
Sound effects	Chorus, Reverberation
Tap tempo switch	Yes
Chorus effects quantity	22
Keyboard number of keys	88
Maximum polyphony (notes)	124
Reverberation effects quantity	9
Power source type	DC
Display type	LCD
Headphone outputs	1

Weight and Dimensions

Depth	405 mm
Width	1320 mm
Height	168 mm
Weight	14900 g
