SPECIFICATIONS
Model Description : multitrack cassette recorder
Mechanical Descriptions
Tape
: standard cassette; CrO2 tape only (EQ: 70µs)
Heads
: hard permalloy 4-channel rec/play head
ferrite 4-channel erase head
Tape speed
: 4.75 cm/sec
Pitch control
: +/-10%
Wow & flutter
: 0.05% WRMS
Fast forward/rewind time
: about 100 seconds (C-60 tape)
Motor
: DC servo
Inputs & Outputs
INPUT 1—4
input impedance
: 10k ohms
rated input level
: - 10dB to - 50dB (input fader in specified position)
minimum input level
:
- 56dB (gain control MAX, input fader MAX)
maximum input level
: + 10dB (gain control MIN, headroom margin)
AUX RTN L/R
input impedance
: 10k ohms
rated input level
: -10dB
ST OUT L/R
output impedance
: 1k ohms
rated impedance load
: 10k ohms or over
rated output level
: - 10dB (at 50k ohms)
AUX SEND
output impedance
: 1k ohms
rated impedance load
: 10k ohms or over
rated output level
: - 10dB (at 50k ohms)
TAPE OUT 1—4
output impedance
: 1k ohms
rated impedance load
: 10k ohms or over
rated output level
: - 10dB (at 50k ohms)
PHONES
rated impedance load
: 8-40 ohms
maximum output level
: 100mW + 100mW
Equalizer Characteristics
HIGH
: +/- 10dB (10kHz shelving)
LOW
: +/- 10dB (100Hz shelving)
Sound Specifications
Total frequency response
: 40Hz—12.5kHz, +/- 3dB
Total signal to noise ratio
: 85dB (dbx ON, IHF-A)
Total distortion
: less than 1% (EIAJ, 315Hz)
Channel separation
: better than 55dB (1 kHz)
Erasure ratio
: better than 70dB
General
Power supply
: supplied AC adaptor (DC 15V), PA11 battery pack (“C” x 10)
Power consumption
: 14w
Dimensions (W x H x D)
: 365mm x 26mm x 225mm (14-1/3” x 2-1/2” x 8-7/8”)
Weight
: 2.5 kg (5.5 Ibs)
Supplied accessories
: carrying strap, PA10 AC adaptor
0dB=0.775Vr.m.s.
Specifications subject to change without notice.
