Dimensions (W × H × D) 449 × 124.6 × 461.7 mm MX200-8
569 × 124.6 × 461.7 mm MX200-12
689 × 124.6 × 461.7 mm MX200-16
929 × 124.6 × 461.7 mm MX200-24
Weight 9.5kg MX200-8
11kg MX200-12
13.5kg MX200-16
17kg MX200-24
0dB=0.775 Vrms
■ Input specifications
Input connectors
Input impedance Nominal impedance
Input level
Connector type
PAD
Gain
Sensitivity Nominal level
Max. before
trim clipping
CH Input
–60 50–600Ω mic
–80dB –60dB –40dB INPUT A
OFF
(77.5µV) (775µV) (7.75mV) XLR 3-31 type
(0dB)
–36dB –16dB +4dB
balanced
4kΩ &
(12.3mV) (123mV) (1.23V)
INPUT B
ON
–16
–16dB +4dB +24dB Phone jack (TRS)
(20dB)
600Ω line
(123mV) (1.23V) (12.3V) T=hot, R=cold, S=GND
AUX RETURN
10kΩ
–12dB +4dB +20dB Unbalanced
(1, 2) (195mV) (1.23V) (7.75V) phone jack
INSERT IN 5kΩ
600Ω line –20dB 0dB +20dB Phone jack (TRS)
(77.5mV) (775mV) (7.75V) T=OUT,R=IN, S=GND
TAPE IN 10kΩ
–26dBV –10dBV
— RCA pin jack
(50.1mV) (316mV)
0dB=0.775 Vrms
0dBV=1 Vrms
■ Output specifications
Output connector Output impedance Nominal impedance
Output level
Connector type
Nominal Max. before clipping
STEREO OUT L/R,
150Ω 600Ω Lines +4dB(1.23V) +24dB (12.3V) XLR-3-32 type
MONO OUT
REC OUT L/R 2kΩ 10kΩ Lines –10dBV (316mV) +16dBV (6.31V) RCA pin jack
AUX SEND 1–475Ω 600Ω Line +4dB (1.23V) +20dB (7.75V) Phone jack
INSERT OUT 600Ω 10kΩ Line 0dB (775mV) +20dB (7.75V)
Phone jack (TRS)
T=OUT, R=IN, S=GND
PHONES (head phone) OUT 100Ω 40Ω Phones 3mW 120mW ST phone jack
0dB=0.775 Vrms
0dBV=1 Vrms
Specifications and appearance are subject to change without notice for product improvement.
