Yamaha MG12 User Manual (English)

Other manuals for Yamaha MG12

Questions and Answers:

M
Mary LamAug 17, 2025
Why are effects not working on my Yamaha Music Mixer?
- R
  Rebecca SerranoAug 17, 2025
  If effects are not being applied on your Yamaha Music Mixer, check that the [FX] knobs for each channel are at suitable levels. Ensure the [ON] button for [FX RTN] is activated. Verify the [PARAMETER] knob and [FX RTN] fader are correctly adjusted. Confirm the [FX RTN] bus assign switch is properly set. If external effects are connected to the [SEND(AUX1 – 4)] jacks, make sure the [AUX1 – 4] knobs for [SEND MASTER] are appropriately set. Check that the power of that device is turned on.
D
darlenesimpsonAug 21, 2025
How to troubleshoot no sound output on Yamaha Music Mixer?
- L
  Linda FoleyAug 21, 2025
  If no sound is coming from the Yamaha Music Mixer, first, ensure external instruments and speakers are correctly connected and that cables aren't shorted. Check if the power of the device is turned on. Then, verify that the [GAIN] knobs for each channel, channel faders, [STEREO] master fader, and [GROUP] faders are at appropriate levels. Also, confirm that the bus assign switches and [LINE /USB] switch are correctly set.
J
joshua86Aug 25, 2025
What to do if there is no sound from [STEREO OUT] jack on Yamaha Music Mixer?
- S
  Shannon BurkeAug 25, 2025
  If you're not getting any sound from the [STEREO OUT] jack on your Yamaha Music Mixer, ensure that the [ON] and [ST] switches for the channels you're using are activated. Also, verify that the [STEREO] master [ON] switch is turned on. Check that the power of that device is turned on.
J
Joshua LynchAug 27, 2025
How to fix no sound output from [SEND (AUX1 – 4)] jacks on Yamaha Music Mixer?
- H
  hlambertAug 27, 2025
  If you're not getting any sound from the [SEND (AUX1 – 4)] jacks on your Yamaha Music Mixer, ensure that the [SEND MASTER] knobs and [AUX 1 – 4] for each channel are appropriately set. When the [PRE] switch for [AUX] is off, confirm that the [ON] switches for the channels you are using are turned on. Check that the power of that device is turned on.
L
Lynn DiazAug 30, 2025
How to improve speaking voice clarity on Yamaha Music Mixer?
- B
  Bernard AllenAug 31, 2025
  If speech is unclear when using your Yamaha Music Mixer, ensure the [HPF] switch is turned on and the equalizer ([HIGH]/[MID]/[LOW]) is properly adjusted. Check that the power of that device is turned on.
A
Amy StevensSep 3, 2025
What causes unstable sound level on Yamaha Music Mixer?
- K
  Kristen SnyderSep 3, 2025
  If the sound level on your Yamaha Music Mixer is unstable and inconsistent, use the [COMP] knob to lower the compressor level, as it may be set too high.
R
Robert HarrisonSep 6, 2025
How to troubleshoot no mixer monitor signal output on Yamaha Music Mixer?
- D
  Devin NelsonSep 6, 2025
  Ensure powered speakers are connected to the [MONITOR OUT] jacks. Adjust the signal output from the [MONITOR OUT] jacks using the [MONITOR LEVEL] knob on your Yamaha Music Mixer.
S
Sherri CalhounSep 9, 2025
Why are left and right levels different on my Yamaha Music Mixer?
- J
  Jake GonzalezSep 9, 2025
  If the left and right levels are different for a stereo signal input on your Yamaha Music Mixer, first ensure that [PAN] is set to the center. If it is, try reversing the left and right input connections. If the low volume switches sides after swapping connections, the issue is with the instrument or device sending the signal. Also, check that you're using the same type of cable for both left and right inputs, as cables with built-in resistors can reduce the signal. Check that the power of that device is turned on.

Yamaha MG12 Specifications

General

Sample rate	192 kHz
Channels quantity	12 channels
Digital sound processing	24 bit
DJ mixer	-
Video capability	No
Monitor out	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Phantom power	48 V
Power consumption (typical)	22 W
Total Harmonic Distortion (THD)	0.03 %

Weight and Dimensions

Depth	422 mm
Width	308 mm
Height	118 mm
Weight	4000 g

Summary

Important Safety Instructions

Safety Guidelines and Warnings

Detailed instructions for safe operation, handling, maintenance, and electrical precautions.

Regulatory and Compliance Information

FCC, UK, and Disposal Notices

Information on FCC compliance, UK plug connection, and equipment disposal procedures.

Precautions

Handling, Location, and Connection Advice

Guidelines on device handling, placement, water warnings, and connection best practices.

Main Features

Product Technology Overview

Highlights D-PRE preamps, universal power supply, digital effects, and USB interface capabilities.

Quick Start Guide

Initial Setup and Power Connection

Steps for preparing the power supply, making connections, and powering up the system.

Quick Start Guide

Achieving Audio Output

Instructions for routing audio signals and adjusting levels for speakers and headphones.

Quick Start Guide

Using Built-in Effects

Guide to selecting, applying, and adjusting built-in effects for enhanced sound.

Setup

Live Performance Connection Examples

Illustrative diagrams for setting up the mixer for live sound reinforcement.

Setup

Events and Party Connection Examples

Illustrative diagrams for connecting the mixer for events and parties.

Controls and Connectors

Front Panel Overview

Detailed identification and explanation of front panel controls and jacks.

Controls and Connectors

Rear Panel Overview

Detailed identification and explanation of rear panel controls and jacks.

Controls and Connectors

Input Channel Block Details

Explanation of mono, stereo input channels, and their respective jacks and controls.

Controls and Connectors

Input Channel Functions Explained

Details on PAD, HPF, GAIN, COMP, and PHANTOM +48V switches and knobs.

Controls and Connectors

Equalizer and AUX Controls

Explanation of EQ settings and AUX send level adjustments for each channel.

Controls and Connectors

PAN/BAL and Bus Assignment Switches

Functionality of PAN/BAL knobs and bus assignment switches for signal routing.

Controls and Connectors

Mono Input Signal Flow Diagram

Block diagram illustrating the signal path for mono input channels.

Controls and Connectors

Stereo Input Signal Flow Diagram

Block diagram illustrating the signal path for stereo input channels.

Built-in Effects Block

Effect Selection and Display

How to select and view built-in effect programs using the display and knobs.

Built-in Effects Block

Parameter Adjustment and FX Routing

Adjusting effect parameters, controlling FX ON/OFF, and assigning effects to buses.

Master Block

Output Jacks and Monitoring Controls

Explanation of output jacks (Send, Group, Stereo, Phones) and monitoring controls.

Master Block

Stereo Outputs and Monitoring Controls

Details on STEREO OUT, PHONES jack, and MONITOR section for signal output and monitoring.

Master Block

Send Master and Group Level Faders

Controls for adjusting levels sent to AUX buses and GROUP outputs.

Master Block

Stereo Master Fader and Power

Operation of the STEREO master fader and the main power switch.

USB Block (XU Models Only)

USB Computer Connectivity and Precautions

Guide to connecting the mixer to a computer via USB, including driver and precautions.

Troubleshooting

No Sound Output Solutions

Steps to diagnose and resolve issues like no sound, low volume, distortion, and balance problems.

Troubleshooting

Setting Controls for Sound Balance

Guidance on adjusting controls for overall sound balance and monitoring individual channels.

Troubleshooting

Addressing Common Sound Issues

Solutions for problems like distortion, noise, unclear voices, and unstable levels.

Appendix

General Specifications

Technical specifications for all mixer models, including input/output channels, power, and dimensions.

Appendix

Built-in Effect Programs List

Comprehensive list of all 24 built-in effects with descriptions of their parameters.

Appendix

Connector Types and Configurations

Explanation of XLR, TRS Phone, TS Phone, and RCA connector types and their signal configurations.

Rack Mounting

Installation Procedures and Precautions

Instructions and safety guidelines for mounting the mixer unit into a standard equipment rack.

Appendix

Manual Index

Alphabetical index of topics covered in the manual with corresponding page numbers for quick reference.
