Controls and features
General view (MX360/MX400, Electric starting models with canister
equipped separately)
1 Fuel tank cap 10 Oil warning light (Red)
2 Air filter case cover 11 Engine switch
3 Carburetor 12 Recoil starter handle
4 Canister assembly 13 Throttle lever
5 Oil drain bolt 14 Fuel cock cup
6 Oil filler cap 15 Fuel cock lever
7 Spark plug 16 Choke lever
8 Muffler 17 Fuel tank filter
9 Fuel tank
9
8
7
6
5
3
2
1
17
16
15
14
13
12
10
11
4
