17
Periodic maintenance
2. Use a flathead screw driver to pry out and remove
the spark arrester from the muffler.
3. Remove the carbon deposits on the spark arrester
using a wire brush.
4. Check the spark arrester.
Replace it if damaged.
5. Install the spark arrester.
Align the spark arrester lump with the hole in the muf-
fler pipe.
6. Install the screw, and then tighten the screw.
1. Spark arrester
When cleaning, use the wire brush lightly to avoid
damaging or scratching of the spark arrester.
1. Hole
2. Spark arrester lump
