Performance for customer Service Tip
Model : MX825V-EFI
10
• Forced lubrication system with trochoid pump
• Trochoid pump with oil strainer and pressure relief valve
• Oil Cooler incorporated (air-cooled, radiator type)
Lubrication
Forced lubrication system
Good reliability and reduced engine wear.
Superior engine lubrication, reliability and reduced wear
Pressurized oil goes to
oil filter and oil cooler
through this hole.
To Oil filter &
Oil cooler
Oil is supplied to the
Crankshaft & Camshaft
after passing thru the oil
cooler.
Trochoid Oil Pump
Trochoid Oil Pump
Oil Strainer
Relief Valve
• Periodical maintenance
Change engine oil: 100hr
Change oil filter : 200hr
