NS-P440/NS-P446
12
NS-P440/NS-P446
✻ New Parts ✻ New Parts
* WG592800 P.C.B. MAIN UC
* WG592900 P.C.B. MAIN RL
* WG593000 P.C.B. MAIN KBG
* WG593100 P.C.B. MAIN A
CB3 VB390100 CN.BS.PIN 5P
s CB4 VG879900 CN.BS.PIN 2P
s CB5‑6 WC050700 CLIP.FUSE EYF‑52BCY RL
s CB7‑8 WC050700 CLIP.FUSE EYF‑52BCY
CB9‑10 VT658100 TERM.WRAP 352‑TX119
C1 UA655100 C.MYLAR 0.1uF50VJ
C2 UA655820 C.MYLAR 0.82uF50VJ
C4 UR867100 C.EL 10uF50V
C5 UA654220 C.MYLAR 0.022uF50VJ
C6 UR867100 C.EL 10uF50V
C7 UA655330 C.MYLAR 0.33uF50VJ
C8 UA655150 C.MYLAR 0.15uF50VJ
C9 UA654100 C.MYLAR 0.01uF50VJ
C10‑11 UR867100 C.EL 10uF50V
C12 UR867470 C.EL 47uF50V
C13 UA655100 C.MYLAR 0.1uF50VJ
C14 UR868100 C.EL 100uF50V
C15 UR838100 C.EL 100uF16V
C16 UR867100 C.EL 10uF50V
C17 UA655150 C.MYLAR 0.15uF50VJ
C18 UA654330 C.MYLAR 0.033uF50VJ
C19 FG652100 C.CE 100pF50V
C21 UA653220 C.MYLAR 2200pF50VJ
C25‑26 WB540200 C.POL.MTL 0.1uF250V
C27 UA655150 C.MYLAR 0.15uF50VJ
C28 UR867100 C.EL 10uF50V
C29 UR867220 C.EL 22uF50V
C30‑32 UR867220 C.EL 22uF50V
C37 UA655470 C.MYLAR 0.47uF50VJ
C38 UA653220 C.MYLAR 2200pF50VJ
s C55 V6185300 C.CE.SAFTY 0.01uF275V
C57 UR868100 C.EL 100uF50V
C58‑59 VU434800 C.EL 4700uF50V
C72 UR867100 C.EL 10uF50V
C74‑75 UA654150 C.MYLAR 0.015uF50VJ
C76 UR838100 C.EL 100uF16V
C77 UR867220 C.EL 22uF50V
C79 FG613100 C.CE 1000pF50V KBG
C81 FG644100 C.CE 0.01uF50V
s D1 VN011300 DIODE.BRG D3SBA204A200V
s D2 VG440900 DIODE.ZENR MTZJ15C15V
s D3 VG440900 DIODE.ZENR MTZJ15C15V
D4 VD631600 DIODE 1SS133,176
D5 VD631600 DIODE 1SS133,176
SW-P440 P.C.B. MAIN SW-P440 P.C.B. MAIN
D6 VD631600 DIODE 1SS133,176
D7 VG442500 DIODE.ZENR MTZJ24B24V
* D8 WG613900 LED 333GD/T5GREEN
D22‑23 VD631600 DIODE 1SS133,176
D24 VU264100 DIODE 1SR139,400
D25 VD631600 DIODE 1SS133,176
s D28‑29 VG437700 DIODE.ZENR MTZJ5.6B5.6V
* F1 WG409700 FUSE 1.6A125V UCRL
F1 KB000660 FUSE 400mA250V KABG
F2 KB000660 FUSE 400mA250V RL
G1 V5995800 PLATE.GND
* s IC1 X5610A00 IC STK404‑070Y60W
IC4‑6 XB247A00 IC uPC4570HA‑A
PJ1 VL552600 JACK.PIN 1P
PN1 WB543700 PIN WB54370L=70#18
Q1 iC224030 TR 2SC2240GR,BL
Q2 iA097030 TR 2SA970GR,BL
Q5 WF612700 TR 2SC2240GR
Q6 iA097040 TR 2SA970GR
Q9 V6896700 TR 2SD2531
Q10 V6896500 TR 2SB1642
Q17‑18 iC224030 TR 2SC2240GR,BL
Q19 iC287820 TR 2SC2878A,B
Q20 iC287820 TR 2SC2878A,B
R1 HV756150 R.CAR.FP 1.5KΩ1/4W
R5 HV756120 R.CAR.FP 1.2KΩ1/4W
R28 V6022600 R.CEMENT 0.1Ω3W
R39 VC760500 R.MTL.OXD 470Ω2W
s R45‑46 HV753100 R.CAR.FP 1Ω1/4W
R47 VC751900 R.MTL.OXD 0.22Ω2W
R48 HV754100 R.CAR.FP 10Ω1/4W
R66 HB026270 R.MTL.FLM 2.7KΩ1/4W
R67 HB028100 R.MTL.FLM 100KΩ1/4W
R95 HV755100 R.CAR.FP 100Ω1/4W
s R126 HV753100 R.CAR.FP 1Ω1/4W
s RY1 VU161600 RELAY DCOSA‑SS‑224DM3
ST1‑3 V4040500 SCR.TERM M3
* s SW5 WG803400 SW.PUSH PS4E‑A‑040‑NP
s SW6 WC906700 SW.SLIDE SDKPA40300 RL
VR1 WC595500 VR A5KΩ
WB419000 HOLDER.LED LDT‑70G
Ref. No. Part No. Description Markets Ref. No. Part No. Description Markets
