Yamaha NX-E440 - Internal View

NS-P440/NS-P446
4
NS-P440/NS-P446
■ INTERNAL VIEW
325 (12-13/16")
198 (7-13/16")
280 (11-1/16") 280 (11-1/16")
295.3 (11-5/8")
12.5
(1/2")
2.8
(1/8")
118
(4-5/8")
110 (4-5/16")
136.8 (5-3/8")
5.4
(3/16")
21.4
(13/16")
SW-P440
NS-E440 NS-C440
99
(3-7/8")
285 (11-3/16") 110 (4-5/16")
129.7
(5-1/8")
1.4
(1/16")
18.3
(3/4")
60
(2-3/8")
60
(2-3/8")
A screw with a diameter of
6 mm (7/32") can be used.
[Hole depth: 15 mm (19/32")]
• DIMENSIONS
1 2 3
467 5
MAIN (3) P.C.B.
MAIN (1) P.C.B.
MAIN (5) P.C.B.
MAIN (9) P.C.B. (R, L models)
MAIN (2) P.C.B.
Power Transformer
MAIN (7) P.C.B. (U, C, K, A, B, G models)
MAIN (10) P.C.B. (R, L models)
1
2
3
4
5
6
7
Unit: mm (inch)
