Option Input (SLOT 1–4) Available cards
Optional digital interface cards (MY8, MY4 series)
Digital Input
(2TR IN DIGITAL 1–3)
SRC
On/off (1:3 and 3:1 maximum input to output sample rate ratio)
Input Channel CH1–56
Input patch
—
Phase
Normal/reverse
Gate-type
*3
On/off
Key in: 12 ch Group (1–12, 13–24, 25–36, 37–48, 49–56)/AUX1–8
Comp-type
*4
On/off
Key in: self /Stereo Link
Pre EQ/pre fader/post fader
Attenuator
–96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
*5
On/off
Delay
0–43400 samples
On/off
—
Fader
100 mm motorized (INPUT/AUX1–8)
Aux send
On/off
AUX1–8; pre fader/post fader
Solo
On/off
Pre fader/after pan
Pan
127 positions (Left= 1–63, Center, Right= 1–63)
Surround pan
127 × 127 positions
LFE level
–∞, –96 dB to +10 dB (256 step)
Routing
STEREO, BUS1–8, DIRECT OUT
Direct out
Pre EQ/pre fader/post fader
Metering
Displayed on LCD
Peak hold on/off
TALKBACK
Level control
Analog rotary potentiometer
AD converter
24-bit linear, 128-times oversampling
Talkback select
Built-in microphone/AD IN 1–16
On/off
—
OSCILLATOR
Level
0 to –96 dB (1 dB step)
On/off
—
Waveform
Sine 100 Hz, sine 1 kHz, sine 10 kHz, pink noise, burst noise
Routing
BUS1–8, AUX1–8, STEREO L, R
STEREO OUT DA converter
24-bit linear, 128-times oversampling
OMNI OUT 1–8
Output patch
SURROUND MONITOR, STEREO, BUS1–8, AUX1–8, DIRECT OUT
1–56, INSERT OUT (CH1–56, BUS1–8, AUX1–8, STEREO)
DA converter
24-bit linear, 128-times oversampling
CONTROL ROOM MONITOR
OUT
Monitor select
STEREO, 2TR IN DIGITAL 1, 2TR IN DIGITAL 2, 2TR IN DIGITAL 3, 2TR
IN ANALOG 1, 2TR IN ANALOG 2, ASSIGN 1, 2 (BUS 1–8/AUX 1–8)
Mono
On/off
Dimmer
On/off
DA converter
24-bit linear, 128-times oversampling
Level control
Analog rotary potentiometer
Phones level
Analog rotary potentiometer
STUDIO MONITOR OUT
Monitor select
CONTROL ROOM, STEREO, AUX 7, AUX 8, TALKBACK
DA converter
24-bit linear, 128-times oversampling
Level control
Analog rotary potentiometer
