Yamaha O2R96 - Dimensions

02R96
7
SURROUND MONITOR
Mute
On/off
Solo
On/off
Source
BUS1–8, SLOT 1–4
Monitor to C-R
On/off
Oscillator
Pink noise/500–2 kHz/1 kHz/50 Hz
Monitor matrix
5.1 → 5.1, 5.1→ 3-1, 5.1 → ST, 3.1 → 3.1, 3.1→ ST
Bass
management
5 presets
Monitor
alignment
ATT (–12.0 dB to 12 dB 0.1 dB step), Delay (0–30.0 msec 0.02 msec
step)
INTERNAL EFFECTS
(EFFECT 1–4)
Bypass
On/off
In/out
8-in, 8-out (EFFECT1): depends on effects type
2-in, 2-out (EFFECT2–4): depends on effects type
Effect-in from
AUX1–8/INSERT OUT/effect-out
Effect-out to
Input patch/effect-in
Power Requirements
U.S.A./Canada 120 V, 60 Hz 200 W
Japan
100 V, 50/60 Hz 190 W
Other 220–240 V, 50/60 Hz 200 W
Dimensions (H x D x W)
239 x 697 x 667 mm (9.4" x 27.4" x 26.3")
Net weight
34 kg (75 lbs)
Operating free-air temperature range
10–35°C (50–95°F)
Storage temperature range
–20 to 60°C (–4 to 140°F)
Supplied Accessories
AC Cable
CD-ROM (Studio Manager)
Options
Digital interface card (MY8, MY4 series)
PEAK METER BRIDGE: MB02R96
SIDE PANEL: SP02R96
*1. Total harmonic distortion is measured with a 6 dB/octave filter @ 80 kHz.
*2. Hum & Noise are measured with a 6 dB/octave filter @ 12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave
attenuation.
*3. See“Gate Parameters” on page 8.
*4. See“Comp Parameters” on page 8.
*5. See“EQ Parameters” on page 7.
LOW/HPF L-MID H-MID HIGH /LPF
Q
0.1–10.0
(41 points)
low shelving
HPF
0.1–10.0
(41 points)
0.1–10.0
(41 points)
high shelving
LPF
F
21.2 Hz–20 kHz (1/12 oct step)
G
±18 dB
(0.1 dB step)
HPF: on/off
±18 dB
(0.1 dB step)
±18 dB
(0.1 dB step)
LPF: on/off
EQ Parameters
