02R96
9
Compander H
Threshold
–54 dB to 0 dB (0.1 dB step)
Ratio (x :1)
x=1, 1.1, 1.3, 1.5, 1.7, 2, 2.5, 3, 3.5, 4, 5, 6, 8, 10, 20 (15 points)
Out gain
–18 dB to 0 dB (0.1 dB step)
Width
1 dB–90 dB (1 dB step)
Attack
0 ms–120 ms (1 ms step)
Release
5 ms–42.3 s (160 points) @ 48 kHz
6 ms–46.0 s (160 points) @ 44.1 kHz
3 ms–21.1 s (160 points) @ 96 kHz
3 ms–23.0 s (160 points) @ 88.2 kHz
Compander S
Threshold
–54 dB to 0 dB (0.1 dB step)
Ratio (x :1)
x=1, 1.1, 1.3, 1.5, 1.7, 2, 2.5, 3, 3.5, 4, 5, 6, 8, 10, 20 (15 points)
Out gain
–18 dB to 0 dB (0.1 dB step)
Width
1 dB–90 dB (1 dB step)
Attack
0 ms–120 ms (1 ms step)
Release
5 ms–42.3 s (160 points) @ 48 kHz
6 ms–46.0 s (160 points) @ 44.1 kHz
3 ms–21.1 s (160 points) @ 96 kHz
3 ms–23.0 s (160 points) @ 88.2 kHz
INPUT 1–16
+48 V switch ON/OFF
PAD switch 0/26 dB
GAIN control –16 to –60 dB
INSERT switch ON/OFF
INPUT 17–24
GAIN control +10 to –34 dB
TALKBACK
TALKBACK LEVEL control
STUDIO MONITOR OUT
STUDIO LEVEL control
CONTROL ROOM MONITOR OUT
CONTROL ROOM LEVEL control
PHONES
PHONES LEVEL control
FADER MODE Section
AUX SELECT
DISPLAY button
AUX 1, AUX 2, AUX 3, AUX 4, AUX 5, AUX 6, AUX 7, AUX 8
buttons (w/LED)
FADER MODE
FADER, AUX button (w/LED)
ENCODER MODE
DISPLAY button
PAN, AUX, ASSIGN 1, ASSIGN 2 buttons (w/LED)
DISPLAY CONTROL Section
DISPLAY ACCESS
buttons
AUTOMIX, DIO, SETUP, UTILITY, MIDI, REMOTE, METER,
VIEW, PAIR, GROUP, INPUT PATCH, OUTPUT PATCH
EFFECTS/PLUG-INS
DISPLAY access, ,
INTERNAL EFFECTS, PLUG-INS, CHANNEL INSERTS, 1, 2, 3, 4
Parameter control: 1, 2, 3, 4
Others
, F1, F2, F3, F4,
buttons
LCD contrast control
Controls
Analog Section
Digital Section
