Yamaha Pacifica 112V User Manual

8
SETTING THE STRING ACTION
— Bridge —
Height adjustment screw
Height adjustment screws
(for each strings)
Height adjustment screw
String Tuning Height
1st E 1.9 mm
2nd B 2.0 mm
3rd G 2.1 mm
4th D 2.2 mm
5th A 2.3 mm
6th E 2.4 mm
String height refers to the space between the strings and frets,
and has an affect on playability.
String height is adjusted with the bridge and/or the saddle on the
bridge. Adjust height by alternately turning the screws little by little
on the left and right sides.
Set too high and the instrument is hard to play. Too low results in
fret noise.
Adjust so that the space between the string and the last fret mea-
sures as follows:
NOTE:
Be sure to perform any necessary adjustments to the
truss rod before performing the following adjustments.
02_EG_om_en_0126.indd 8 16/01/26 14:29

Yamaha Pacifica 112V Specifications

General

Body Material	Alder
Neck Material	Maple
Fingerboard Material	Rosewood
Scale Length	25.5 inches
Number of Frets	22
Bridge	Vintage-style tremolo
Controls	Master Volume, Master Tone, 5-position pickup selector
Tuners	Die-cast
Finish	Gloss Polyurethane
Nut Width	41mm
Pickups	Alnico V Humbucker (Bridge), Alnico V Single-Coil (Middle), Alnico V Single-Coil (Neck)
