PSR-A1000 Data List
34
TOTAL SIZE 04
TOTAL SIZE 0C
nn = PART NUMBER
If there is a Drum Voice assigned to the part, the following parameters are ineffective.
• BANK SELECT LSB
• MONO/POLY MODE
• SCALE TUNING
• PORTAMENTO
• PITCH EG
• FILTER MODULATION DEPTH (FMOD DEPTH)
• AMPLITUDE MODULATION DEPTH (AMOD DEPTH)
MIDI Parameter Change table (DRUM SETUP)
TOTAL SIZE 10
TOTAL SIZE 0E
n: Drum Setup Number (0-1)
rr: note number (0D-5B)
In the following cases, PSR-A1000 will initialize all Drum Setups.
XG SYSTEM ON received
GM SYSTEM ON received
DRUM SETUP RESET received (only when in XG mode)
[Note]
When a part to which a Drum Setup is assigned receives a program change, the assigned Drum Setup will be initialized.
If the same Drum Setup is assigned to two or more parts, changes in Drum Setup parameters (including program changes) will apply to all parts to which it is
assigned.
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
Corresponding Voice MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
Regular Voice Song Main Layer Left Keyboard Style Extra
Panel
(main generation method)
M.Pad Style Song MIDI
70 1 NOT USED — — — — — — — — — — — —
71 1 NOT USED — — — — — — — — — — — —
72 1 00-7F EQ BASS GAIN –12dB…+12dB 40 O O O X O O O (Mixing Console) O O O X
73 1 00-7F EQ TREBLE GAIN –12dB…+12dB 40 O O O X O O O (Mixing Console) O O O X
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
Corresponding Voice MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
Regular Voice Song Main Layer Left Keyboard Style Extra
Panel
(main generation method)
M.Pad Style Song MIDI
74 1 NOT USED — — — — — — — — — — — —
75 1 NOT USED — — — — — — — — — — — —
76 1 04-28 EQ BASS
FREQUENCY
32…2.0k [Hz] 0C O O O X X O O (Sound Creator) O X O X
77 1 1C-3A EQ TREBLE
FREQUENCY
500…16.0k
[Hz]
36 O O O X X O O (Sound Creator) O X O X
78 1 NOT USED — — — — — — — — — — — —
79 1 NOT USED — — — — — — — — — — — —
7A 1 NOT USED — — — — — — — — — — — —
7B 1 NOT USED — — — — — — — — — — — —
7C 1 NOT USED — — — — — — — — — — — —
7D 1 NOT USED — — — — — — — — — — — —
7E 1 NOT USED — — — — — — — — — — — —
7F 1 NOT USED — — — — — — — — — — — —
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
Corresponding Voice MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
Regular Voice Song Main Layer Left Keyboard Style Extra
Panel (main generation
method)
M.Pad Style Song MIDI
3n rr 0 1 00-7F PITCH COARSE –64…0…+63 40 O (Drum only) O X X X X X X O O X
1 1 00-7F PITCH FINE –64…0…+63
[cent]
40 O (Drum only) O X X X X X X O O X
2 1 00-7F LEVEL 0…127 Depends on the note O (Drum only) O X X X X X X O O X
3 1 00-7F ALTERNATE
GROUP
OFF, 1…127 Depends on the note O (Drum only) O X X X X X X X O X
4 1 00-7F PAN RND,
L63…C…R63
Depends on the note O (Drum only) O X X X X X X O O X
5 1 00-7F REVERB SEND 0…127 Depends on the note O (Drum only) O X X X X X X O O X
6 1 00-7F CHORUS SEND 0…127 Depends on the note O (Drum only) O X X X X X X O O X
7 1 00-7F VARIATION SEND 0…127 7F O (Drum only) O X X X X X X O O X
8 1 00-01 KEY ASSIGN SINGLE, MULTI 0 O (Drum only) O X X X X X X X O X
9 1 00-01 Rcv NOTE OFF OFF, ON Depends on the note O (Drum only) O X X X X X X X O X
0A 1 00-01 Rcv NOTE ON OFF, ON 1 O (Drum only) O X X X X X X X O X
0B 1 00-7F LOW PASS FILTER
CUTOFF FRE-
QUENCY
–64…0…+63 40 O (Drum only) O X X X X X X O O X
0C 1 00-7F LOW PASS FILTER
RESONANCE
–64…0…+63 40 O (Drum only) O X X X X X X O O X
0D 1 00-7F EG ATTACK RATE –64…0…+63 40 O (Drum only) O X X X X X X O O X
0E 1 00-7F EG DECAY1 RATE –64…0…+63 40 O (Drum only) O X X X X X X O O X
0F 1 00-7F EG DECAY2 RATE –64…0…+63 40 O (Drum only) O X X X X X X O O X
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
Corresponding Voice MIDI Reception (effective or not for each part) MIDI Transmission (generated data)
Regular Voice Song Main Layer Left Keyboard Style Extra
Panel (main generation
method)
M.Pad Style Song MIDI
20 1 00-7F EQ BASS GAIN –12…+12 [dB] 40 X X X X X X X X X X X
21 1 00-7F EQ TREBLE GAIN –12…+12 [dB] 40 X X X X X X X X X X X
22 1 NOT USED — — — — — — — — — — — —
23 1 NOT USED — — — — — — — — — — — —
24 1 04-28 EQ BASS FRE-
QUENCY
32…2.0k [Hz] 0C X X X X X X X X X X X
25 1 1C-3A EQ TREBLE FRE-
QUENCY
500…16.0k
[Hz]
36 X X X X XX X X XXX
26 1 NOT USED — — — — — — — — — — — —
27 1 NOT USED — — — — — — — — — — — —
28 1 NOT USED — — — — — — — — — — — —
29 1 NOT USED — — — — — — — — — — — —
2A 1 NOT USED — — — — — — — — — — — —
2B 1 NOT USED — — — — — — — — — — — —
2C 1 NOT USED — — — — — — — — — — — —
2D 1 NOT USED — — — — — — — — — — — —
To Next Page
