PSR-A1000 Data List
36
System Exclusive Messages (Universal Realtime messages)
System Exclusive Messages (Universal Non Realtime messages)
System Exclusive Messages (XG)
MIDI
Event
Data Format
Corresponding Voice
MIDI Reception
(effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular Voice Song
Main
Layer
Left
Key-
board
Style Extra
Panel (main
generation
method)
M.Pad Style Song MIDI
Master
Volume
F0 7F 7F 04 01 ll mm F7 O O X X X X X X X X X
(Output as
XG Master
Volume)
X
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
01111111 7F = ID of target device
00000100 04 = Sub-ID #1=Device Control Message
00000001 01 = Sub-ID #2=Master Volume
0lllllll ll = Volume LSB
0mmmmmmm mm = Volume MSB
11110111 F7 = End of Exclusive
or
F0 7F XN 04 01 ll mm F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is
received. X = ignored
00000100 04 = Sub-ID #1=Device Control Message
00000001 01 = Sub-ID #2=Master Volume
0lllllll ll = Volume LSB
0mmmmmmm mm = Volume MSB
11110111 F7 = End of Exclusive
MIDI
Event
Data Format
Corresponding Voice
MIDI Reception
(effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular Voice Song
Main
Layer
Left
Key-
board
Style Extra
Panel (main
generation
method)
M.Pad Style Song MIDI
General
MIDI
System
On
F0 7E 7F 09 01 F7 O O X X X O O
(Mixing Con-
sole)
XXXO X
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
01111111 7F = ID of target device
00001001 09 = Sub-ID #1=General MIDI Message
00000001 01 = Sub-ID #2=General MIDI On
11110111 F7 = End of Exclusive
or
F0 7E XN 09 01 F7
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
0xxxnnnn XN = When N is received N=0-F, whichever is
received. X=ignored
00001001 09 = Sub-ID #1=General MIDI Message
00000001 01 = Sub-ID #2=General MIDI On
11110111 F7 = End of Exclusive
MIDI
Event
Data Format
Corresponding Voice
MIDI Reception
(effective or not for each part)
MIDI Reception
(affecting the
panel)
MIDI Transmission (generated data)
Regular Voice Song
Main
Layer
Left
Key-
board
Style Extra
Panel (main
generation
method)
M.Pad Style Song MIDI
XG
Parame-
ter
Change
F0 43 1n 4C hh mm ll dd … F7
* Refer to Parame-
ter Change Table
* Refer to Parameter Change
Ta bl e
— * Refer to Parameter Change Table O (When
receiving
the XG
Parameter
Request)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0001nnnn 1n = Device Number n=always 0 (when transmit),
n=0-F (when receive)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
: :
11110111 F7 = End of Exclusive
XG Bulk
Dump
F0 43 0n 4C aa bb hh mm ll dd … dd cc F7
* Refer to Parame-
ter Change Table
* Refer to Parameter Change
Ta bl e
— X X X X (Output
as Parame-
ter Change)
O (When
receiving
the XG
Dump
Request)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0000nnnn 0n = Device Number n=always 0 (when transmit),
n=0-F (when receive)
01001100 4C = Model ID
0aaaaaaa aa = Byte Count MSB
0bbbbbbb bb = Byte Count LSB
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
: :
0ddddddd dd = Data
0ccccccc cc = Checksum
11110111 F7 = End of Exclusive
XG
Parame-
ter
Request
F0 43 3n 4C hh ll F7 — — — — — — O
(—)
XXXX X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0011nnnn 3n = Device Number n=always 0 (when transmit),
n=0-F (when receive)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
XG
Dump
Request
F0 43 2n 4C hh mm ll F7 — — — — — — O
(—)
XXXX X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0010nnnn 2n = Device Number n=always 0 (when transmit),
n=0-F (when receive)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
