PSR-E433/PSR-I455

CIRCUIT BOARDS（シート基板図）

AMJK Circuit Board (YD798C0) ............................................................................................... 24

DMLCD Circuit Board (YD972C0, YE710A0) ...................................................................... 25/26

ENC(EN) Circuit Board (YD797C0) .......................................................................................... 25

MVR Circuit Board (YD797C0) ................................................................................................. 25

PB Circuit Board (YD797C0) .................................................................................................... 26

PNL Circuit Board (YD797C0) .................................................................................................. 27

PNR Circuit Board (YD797C0) ................................................................................................. 28

TW Circuit Board (YD797C0) ................................................................................................... 26

VR Circuit Board (YD798C0) .................................................................................................... 28

61H-MK Circuit Board (X2335D0) ............................................................................................ 29

61L-MK Circuit Board (X2336C0) ............................................................................................ 29

Note: See parts list for details of circuit board component parts.

注 : シートの部品詳細はパーツリストをご参照ください。

Note: The DMLCD circuit boards “YD972C0” and “YE710A0” are shared parts.

注 : DMLCDCircuitBoard(YD972C0,YE710A0) は併用使用です。

to TW (Left side)to TW (Right side)

to WOOFER L

to WOOFER R

to DMLCD-CN201 to MVR-CN390

to PNL-CN360

to Battry terminals

(電池端子)

to Back light assembly

(バックライトAssy)

AMJK Circuit Board

AMJK: 2NA-WZ26850
