Yamaha QL Series - General Specifications; Analog output specifications; Digital inputoutput specifications; IO SLOT (1-2) specifications

General Specifications
Sampling Frequency
Internal
44.1kHz
48kHz
External
44.1kHz
+4.16 67% , + 0.1% , – 0.1%, – 4.0 %
±200ppm
48kHz
+4.16 67% , + 0.1% , – 0.1%, – 4.0 %
±200ppm
Signal Delays Less than 2.5ms, INPUT to OMNI OUT, Fs= 48kHz
Fader
100mm motorized, Resolution=1024steps
+10dB to –138dB, –∞dB all faders
Frequency Response
+0.5, –1.5dB 20Hz-20kHz,
refer to +4dBu output @1kHz INPUT to OMNI OUT
Total Harmonic
Distortion
*3
Less than 0.05% 20Hz-20kHz@+4dBu into 600Ω
INPUT to OMNI OUT, Input Gain= Min.
Hum & Noise
*4
–128dBu typ., Equivalent Input Noise, Input Gain= Max.,
–88dBu, Residual output noise, ST master off
Dynamic Range
112dB typ., DA Converter,
108dB typ., INPUT to OMNI OUT, Input Gain= Min.
Crosstalk@1kHz –100dB
*1
, adjacent INPUT/OMNI OUT channels, Input Gain= Min.
Dimensions (WxHxD)
and Net Weight
QL5: 828mm x 272mm x 563mm (32.6in x 10.7in x 22.2in), 21.8kg (48.1lb)
QL1: 468mm x 272mm x 562mm (18.4in x 10.7in x 22.1in), 14.7kg (32.4lb)
Power Requirements
(in watts)
QL5: 200W
QL1: 135W
Power Requirements
(in volts,Hz)
100-240V 50/60Hz
Temperature Range Operating temperature range: 0 - 40℃, Storage temperature range: -20 - 60℃
Included Accessories Owner’s Manual, dust cover (QL5 only), power cord, DVS license sheet
Optional Accessories
Rackmount kit RK1 (QL1 only), Mini-YGDAI cards
*2
,
Gooseneck Lamp LA1L, Nuendo Live
Digital input/output specications
Connectors Format Data length Level Audio Connector
Primary/Sec-
ondary
Dante 24bit or 32bit 1000Base-T
64ch Input/64ch
Output@48kHz
*1
EtherCON Cat5e
I/O SLOT (1-2) specications
Each I/O Slot accepts a Mini-YGDAI card.
Only Slot 1 has a serial interface.
Digital output specications
Connectors Format Data length Level Connector
DIGITAL OUT AES/EBU AES/EBU Professional Use 24bit RS422 XLR-3-32 type (Balanced)
*1
*1. A 22kHz, 30dB/Oct filter is used to measure crosstalk.
*2. For more information about Mini-YGDAI card support, refer to the Yamaha pro audio website.
http://www.yamahaproaudio.com/
*3. An 80kHz, 18dB/Oct filter is used to measure total harmonic distortion.
*4. An A-Weight filter is used to measure hum & noise.
Input/Output Specifications
Analog input specications
Input
Connectors
GAIN
Input
Impedance
Source
Impedance
Input Level
Connector
Sensitivity
*1
Nominal Max. before clip
INPUT
1-32
*6
+66dB
7.5 kΩ
50-600 Ω
Mics &
600 ΩLines
–82dBu
(61.6μV)
–62dBu
(0.616mV)
–42dBu
(6.16mV )
XLR-3-31
type
(Balanced)
*2
–6dB
–10dBu
(245mV)
+10 dBu
(2.45V)
+30dBu
(24.5V)
*1. The sensitivity is the input level required for output at +4dBu (1.23V) or at the defined level when all the faders and level
controllers are set to the maximum value.
*2. XLR-3-31 connectors are balanced jacks (1=GND, 2=HOT, 3=COLD).
*3. 0dBu=0.775 Vms for all specifications.
*4. All the AD converters use 24-bit linear/128-times oversampling.
*5. The INPUT connectors have +48V DC (phantom power) jacks, each of which can be turned on/off individually from the
console software.
*6. QL1: INPUT1-16
Analog output specications
Output
Connectors
Output
Impedance
Load
Impedance
Maximum
Output
Level
*5
Output Level
Connector
Dened
Level
Maximum
Non-Clip Level
OMNI
OUT 1-16
*7
75 Ω
600 Ω
Lines
+24dB
(default)
+4dBu
(1.23V)
vt+24dBu
(12.3V)
XLR-3-32 type
(Balanced)
*1
+18dB
–2dBu
(616mV)
+18dBu
(6.16V )
PHONES 15 Ω
8 Ω
Phones
– 75mW
*6
150mW
Stereo Phone
Jack(TRS)
(Unbalanced)
*2
40 Ω
Phones
– 65mW
*6
150mW
Control I/O specications
Connectors Format Level Connector
MIDI
IN MIDI – DIN Connector 5P
OUT MIDI – DIN Connector 5P
WORDCLOCK
IN – TTL/75 Ω terminated BNC Connector
OUT – TTL/75 Ω BNC Connector
GPI (5IN/5OUT) – – D Sub Connector 15P(Female)
*1
NETWORK IEEE802.3 10BASE-T/100Base-TX RJ-45
LAMP (QL5: x 2, QL1: x 1) – 0V-12V XLR-4-31 type
*2
USB HOST USB 2.0 – USB A Connector (Female)
*1. XLR-3-32 connectors are balanced jacks (1=GND, 2=HOT, 3=COLD).
*2. The PHONES connectors for stereo headphones are balanced jacks (Tip=LEFT, Ring=RIGHT, Sleeve= GND).
*3. 0 dBu=0.775 Vms for all specifications.
*4. All the DA converters use 24-bit linear/128-times oversampling.
*5. The console has an internal switch for toggling the maximum output level.
*6. This is a value measured with the PHONES LEVEL knob set to 10 dB below the maximum position.
*7. QL1: OMNI OUT 1-8
*1. XLR-3-32 connectors are balanced jacks (1=GND, 2=HOT, 3=COLD).
*1. QL1: 32ch Input/32ch Output@48kHz
*1. Input pin: TTL level, w/ internal pull-up (47kΩ) Output pin: Open drain output (Vmax=12V, maximum sink current/pin=-
75mA) Power supply pin: Output voltage Vp=5V, Max. output current=300mA
*2. 4 pin=+12V, 3 pin=GND, Lamp nominal power: 5W, Brightness (voltage) can be adjusted from the software.
