CS-R3 Owner’s Manual
14
C SCENE MEMORY section
1 [OVERLAY] key
Press this button to display the OVERLAY SETTING
screen.
While pressing and holding down the [SHIFT] key
(see 4 on page 17), press the [OVERLAY] key to
switch Overlay on or off.
While Overlay is turned on, press and hold down the
[OVERLAY] key to enter Overlay edit mode.
2 [UNDO] key
Cancels the most recent scene operation of storing,
recalling or updating a scene.
After you cancel the operation by pressing the [UNDO]
key, you can “redo” the canceled operation by pressing
the [UNDO] key again.
NOTE
Using the [UNDO] key will not undo an operation to store a
new scene.
3 [UPDATE] key
Updates scene data by overwriting the current scene
(that has been recalled most recently) with the
current mix data.
4 [PREVIEW] key
Switches Preview mode on or off.
5 [STORE] key
Stores the current scene settings as the new settings.
If you select the existing scene as the store
destination, it will be overwritten.
NOTE
Use the [UPDATE] key to overwrite the current scene.
6 [INC]/[DEC] keys
Enable you to select the scene number of a scene that
you want to store or recall.
NOTE
• If you select a scene other than the current scene, the
scene number on the LCD display will flash.
• Press the [INC] and [DEC] keys simultaneously to return
to the current scene.
7 [RECALL] key
Enables you to recall a selected scene from scene
memory.
RANGE
AB
AB
GAIN
ENCODER
ASSIGN
HOME
VIEW
ASSIGN
SENDS ON
FADER
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12123456789101112
USER DEFINED
KEY
THRESHOLD
ATTACK
ATTACK RELEASE
DECAYHOLD
KNEE
RATIO OUTGAIN
TOUCH AND TURN
E2
123456789101112
123456789101112
USER DEFINED
KEY
E1
GAIN
GAIN
GAIN
SENDS ON
FADER
SENDS ON
FADER
123456789101112
TALKB AC K
MONITORUSER DEFINED KEYS
1234
5678
9101112
1234
5678
9101112
BANK
CC
/ BANK
D
/
SYSTEM
POWER
A
B
USB
RECORDING
ON
DECDEC INCINC
OVERLAY UNDO
SCENE MEMORY
UPDATE PREVIEW
STORE RECALL
DEC INC
OVERLAY UNDO
SCENE MEMORY
UPDATE PREVIEW
STORE RECALL
