RM1x
5
2 3
1
13
16
17
4
16
5
6
15
1914
9
8
18
9
11
7
10
12
1. BPM Display
2. MIDI Data Monitors
3. LCD Display
4. Display Knobs
5. Function Buttons and Indicators
6. VOLUME Control
7. Real Time Controller Knobs & [KNOB] Button
8. Cursor Buttons
9. [NO -1] and [YES +1] Buttons
10. DISPLAY [<-] and [->] Buttons
11. MODE and SUBMODE Buttons
12. [EXIT] Button
13. Sequencer Buttons and Indicators
14. Keyboard
15. Keyboard Mode Buttons
16. [OCT DOWN] and [OCT UP] Buttons
17. [SHIFT] Button
18. [ARPEGGIO ON] Button
19. [TAP/ENTER] Button
PANEL LAYOUT
