9-12
9
To change the engine oil
1. Park the vehicle on a level surface.
2. Start the engine, warm it up for several
minutes, and then turn it off.
3. Lift the cargo bed up.
4. Place an oil pan under the oil tank to col-
lect the used engine oil.
5. Remove the engine oil tank filler cap and
the cylinder head cap.
6. Remove the engine oil tank drain bolt and
its gasket to drain the engine oil from the
oil tank. (Use a trough or a similar object
as shown to prevent oil from spilling on
the frame.)
1. Cylinder head cap
2. Engine oil tank filler cap
1. Engine oil tank drain bolt
2. Gasket
UB4M13E0.book Page 12 Thursday, June 24, 2021 2:40 PM
