Steering shaft lubrication

Lubricate the pivot points.

EBU32610

Wheel removal

1. Loosen the wheel nuts.

2. Elevate the vehicle and place a suitable

stand under the frame.

3. Remove the nuts from the wheel.

4. Remove the wheel.

Recommended lubricant:

Lithium-soap-based grease

Recommended lubricant:

Lithium-soap-based grease
