9-39
9
5. Install the bolts and tighten them to the
specified torque.
EBU32460
Valve clearance
The correct valve clearance changes with
use, resulting in improper fuel/air supply or
engine noise. To prevent this, the valve clear-
ance must be adjusted regularly. This adjust-
ment however, should be left to a
professional Yamaha service technician.
EBU32470
Brakes
Replacement of brake components requires
professional knowledge. Brake service
should be performed by a Yamaha dealer.
EWB02572
Operating with improperly serviced or ad-
justed brakes could lead to a loss in brak-
ing ability and an accident.
EBU35150
Checking the front and rear brake pads
Check each brake pad for damage and mea-
sure the lining thickness. If a brake pad is
damaged or if the lining thickness is less than
1.0 mm (0.04 in), have a Yamaha dealer re-
place the brake pads as a set.
1. Tailpipe
Tightening torque:
Tailpipe bolt:
10 N·m (1.0 kgf·m, 7.4 lb·ft)
UB4M13E0.book Page 39 Thursday, June 24, 2021 2:40 PM
