9-38
9
2. Remove the tailpipe by pulling it out of
the muffler, and then remove the gasket.
3. Tap the tailpipe lightly, and then use a
wire brush to remove any carbon depos-
its from the spark arrester portion of the
tailpipe and inside of the tailpipe housing.
4. Install the gasket, and then insert the tail-
pipe into the muffler and align the bolt
holes.
Make sure that the tailpipe is positioned at a
48° angle as shown.
1. Tailpipe bolt
1. Tailpipe
2. Spark arrester
3. Gasket
