Yamaha RMAX WOLVERINE 2021 - Page 133

9-22
9
TIP
The oil level should be between the minimum
and maximum level marks.
6. If the oil level is at or below the minimum
level mark, add oil.
TIP
Add a sufficient amount to raise to the maxi-
mum level mark, but do not overfill.
7. Install the dipstick.
8. Install the rubber cover.
9. Install the passenger seat cushion.
To change the transmission oil
1. Place an oil pan under the transmission
case to collect the used oil.
2. Remove the transmission oil dipstick.
3. Remove the transmission oil drain bolt
and gasket.
1. Arrow mark
1
1. Transmission oil drain bolt
2. Gasket
2
1
UB4M13E0.book Page 22 Thursday, June 24, 2021 2:40 PM
