9-55
9
1. Turn off all electrical systems. (See page
5-1.)
2. Remove the hood. (See page 9-9.)
3. Remove the blown fuse, and then install a
new fuse of the specified amperage.
WARNING! Always use a fuse of the
specified amperage. Never use any
material in place of the proper fuse.
Using an improper fuse can cause
damage to the electrical system and
may lead to a fire.
[EWB03440]
Specified fuses:
Main fuse:
50.0 A
Fuel injection system fuse:
10.0 A
Headlight fuse:
7.5 A
Ignition fuse:
15.0 A
Auxiliary DC jack fuse:
10.0 A
Signaling system fuse:
7.5 A
Four-wheel-drive motor fuse:
7.5 A
Radiator fan motor fuse:
30.0 A
ETV fuse:
10.0 A
Accessory fuse:
20.0 A
Backup fuse:
7.5 A
EPS fuse:
40.0 A
SCU fuse:
15.0 A (YXE10WRLN)
