5-32
5
Slow compression damping force adjusting
screw
YXE10WRLN:
Spring preload adjusting nut
Suspension mode
This vehicle is also equipped with a suspen-
sion mode switch which makes it possible to
adjust the damping force. See page 5-19 for
more information on selecting the suspension
mode.
EWB04470
Suspension components become hot
during operation. Never touch the com-
pression damping force adjuster or ad-
justing bolt and screw or the oil reservoir
with your bare hand or skin until suspen-
sion components have cooled.
Always adjust the shock absorber as-
semblies on the left and right side to the
same setting. Uneven adjustment can
cause poor handling and loss of stability,
which could lead to an accident.
ECB00091
Never turn an adjusting mechanism be-
yond the minimum and maximum settings.
Spring preload
1. Elevate the vehicle and place a suitable
stand under the frame.
2. Loosen the locknut.
3. Turn the spring preload adjusting nut in
direction (a) to increase the spring pre-
load and thereby harden the suspension,
and in direction (b) to decrease the spring
preload and thereby soften the suspen-
sion.
UB4M13E0.book Page 32 Thursday, June 24, 2021 2:40 PM
