R
3-4
INSTRUMENT AND CONTROL FUNCTIONS
/home/Imai/imai_data/YMC-om/AB9239_RT100-26/English/E-3.frame
1. Oil tank filler cap
Recommended oil:
Yamalube 2 or 2-stroke engine oil
(JASO FC grade or ISO EG-C,
EG-D grade)
Oil tank capacity:
1,0 L
1. Arrow mark positioned over ÒOFFÓ
EAU01121
Fuel cock
The fuel cock supplies fuel from the
tank to the carburetor while filtering it
also.
The fuel cock has three positions:
OFF
With the lever in this position, fuel will
not flow. Always return the lever to this
position when the engine is not run-
ning.
1. Arrow mark positioned over ÒONÓ
ON
With the lever in this position, fuel flows
to the carburetor. Normal riding is done
with the lever in this position.
