INPUT: AV5 ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Sub-memu Input level Volume
SPEAKERS OUTPUT SUB-
WOOFER
OUTPUT
FRONT L/R CENTER
SURROUND
L/R
SURROUND
BACK L/R
PRESENCE/
ZONE2
A4-1. BI-AMP
Both ch,
-20 dBm
+6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm +13.0 dBm - ∞ -6.5 dBm
A4-2. ZONE/TONE=MAX
Both ch,
-20 dBm
+6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm - ∞ +13.0 dBm -6.5 dBm
A4-3. ZONE/TONE=MIN
Both ch,
-20 dBm
+6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm - ∞ +13.0 dBm -6.5 dBm
A4-4.
INVALID ITEM
(Not for service)
Both ch,
-20 dBm
+6.5 dB – – – – – –
A4-5.
INVALID ITEM
(Not for service)
Both ch,
-20 dBm
+6.5 dB – – – – – –
A4-6. D-PARTY MODE
Both ch,
-20 dBm
+6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm - ∞ +13.0 dBm -6.5 dBm
A4-7. FULL MUTE
Both ch,
-20 dBm
+6.5 dB - ∞ - ∞ - ∞ - ∞ - ∞ - ∞
A4-8.
INVALID ITEM
(Not for service)
Both ch,
-20 dBm
+6.5 dB – – – – – –
A4-9.
INVALID ITEM
(Not for service)
Both ch,
-20 dBm
+6.5 dB – – – – – –
A4-10.
INVALID ITEM
(Not for service)
Both ch,
-20 dBm
+6.5 dB – – – – – –
A6-1
MICROUTE
A6. MIC CHECK
A6-1. MIC ROUTE CHECK
The signals input through the YPAO microphone are output to FRONT L and FRONT R channels via A/D-D/A.
A5-1
8ohmMULTICH
A5-2
6ohmMULTICH
A5. MULTI CHANNEL INPUT
Not for service.
