Yamaha RX-A710 - Self-Diagnostic Function

This unit has self-diagnostic functions that are intended for inspection, measurement and location of faulty point.
There are 25 main menu items, each of which has sub-menu items.
Listed in the table below are main menu items and sub-menu items.
Note that not all menu items listed will apply to the models covered in this service manual.
■ SELF-DIAGNOSTIC FUNCTION
No. Main menu No. Sub-menu
A: Audio system
A1 DSP AUDIO 1 DSP MARGIN
2 DSP NON MARGIN
3 INVALID ITEM
(Not for service)
4 DSP FULL CENTER
5 DSP FULL SURROUND
6 DSP FULL SURROUND BACK
7 DSP FULL SUBWOOFER
A2 DIRECT AUDIO 1 ANALOG DIRECT VH
2 ANALOG DIRECT VL
A3 HDMI AUDIO 1 HDMI AUTO
2 INVALID ITEM
(Not for service)
3 ARC1
4 INVALID ITEM
(Not for service)
A4 SPEAKERS SET 1 BI-AMP
2 ZONE/TONE=MAX
3 ZONE/TONE=MIN
4 INVALID ITEM
(Not for service)
5 INVALID ITEM
(Not for service)
6 D-PARTY MODE
7 FULL MUTE
8 INVALID ITEM
(Not for service)
9 INVALID ITEM
(Not for service)
10 INVALID ITEM
(Not for service)
A5 MULTI CHANNEL INPUT 1 8 CHANNEL INPUT 8 ohms
(Not for service)
2 8 CHANNEL INPUT 6 ohms
A6 MIC CHECK 1 MIC ROUTE CHECK
A7 MANUAL TEST 1 TEST ALL
2 TEST FRONT L
3 TEST CENTER
4 TEST FRONT R
5 TEST SURROUND R
6 TEST SURROUND BACK R
7 TEST SURROUND BACK L
8 TEST SURROUND L
9 TEST FRONT PRESENCE L
10 TEST FRONT PRESENCE R
11 INVALID ITEM
(Not for service)
12 INVALID ITEM
(Not for service)
13 TEST LFE 1
14 INVALID ITEM
(Not for service)
D: Display system
D1 FL CHECK 1 FL CHECK
2 ALL SEGMENT OFF
3 ALL SEGMENT ON
4 CHECK PATTERN 1
5 CHECK PATTERN 2
26
